ITT CANNON KPT07E106S Miniature Circular Connector
The KPT07E10-6S from ITT Cannon is a rugged miniature circular connector designed for harsh environments. It features a MIL-DTL-26482 Series I compatible jam nut receptacle with six solder cup contacts (size 20), and an aluminum alloy body coated with olive drab chromate over cadmium for corrosion resistance. The connector supports up to 500 mating cycles, maintains IP67/IP68 sealed environment against water and dust, and withstands temperatures from -55°C to +125°C. With high shock and vibration resistance, this durable connector is ideal for industrial, military, and automation applications, ensuring reliable performance in demanding conditions.
ITT CANNON KPT07E106S Miniature Circular Connector Specifications:
- Shell Style: Jam nut receptacle
- Shell Size: 10
- Contact Arrangement: 10-6
- Number of contacts: 6 (size 20) solder cup
- Contact Material: Copper alloy, gold plated (size 16), tin (size 20)
- Shell Material: Aluminum alloy with olive drab chromate over cadmium plating
- Insulator and Grommet Material: Polychloroprene
- Water Tightness: IP67/IP68 according to DIN 40 050, 0.2 bar pressure over 48 hours
- Operating Temperature: -55°C to +125°C
- Mating Cycles: Minimum 500
- Vibration Resistance: 200 m/s² at 10 to 2000 Hz
- Insulator Resistance: 5000 MΩ
- Test Voltage: 1500 Vrms
- Supporting Standards: VG95319, VG95210
- Sealing: Environmentally sealed against water and dust
- Construction: Aluminum alloy body, neoprene insulator, copper alloy contacts with gold or tin plating
- Compatibility: Intermateable with MIL-DTL-26482 Connectors
- Additional Features: Quick disconnect bayonet coupling, keyway polarization, high contact density
Buy the Buy ITT Circular Connector Part Number KPT07E10-6S Online
Purchase the ITT KPT07E10-6S connector online today to benefit from its rugged design, high environmental sealing, and temperature resilience. Perfect for demanding industrial, military, and automation applications, this connector offers quick assembly, durability, and compatibility with MIL standards. With corrosion-resistant materials, a robust IP67/IP68 seal, and high vibration and shock resistance, it guarantees dependable performance even in extreme conditions. Place your order now and equip your project with a reliable, cost-effective connection solution that meets strict industry standards.
Order your ITT SeriesKPT KPT07E10-6S today and ensure reliable performance in harsh industrial and military environments with this compact, sealed connector.
