ITT CANNON DDM24W7PK87 D-Subminiature Connector
The DDM24W7PK87 is a 7-position combination D-sub connector with solder pot contacts, featuring a black thermoplastic insulator rated UL94V-0 and a steel shell with tin finish. Designed for a wide wire gauge range of 8-26 AWG, it supports a maximum current of 7.5A for signal contacts and exhibits a contact resistance of 10 milliohms. The connector is suitable for computer and peripheral applications and offers reliable performance with a dielectric withstand voltage of 500 VAC at sea level. It supports 50 mating cycles and operating temperatures from -55°C to +125°C, ensuring durability in various environments.
ITT CANNON DDM24W7PK87 D-Subminiature Connector Specifications:
- Wire Gauge Range: 8-26 AWG
- Mating Cycles: 50
- Contact Arrangement: 17 contacts size 20, 7 empty size 8 cavities
- Dielectric Withstanding Voltage: 500 VAC at sea level
- Current Rating: 7.5A max for signal contacts
- Contact Resistance: 10 milliOhm max
- Operating Temperature: -55°C to +125°C
- Shell Material: Steel with tin finish
- Shell Finish: Pure tin over nickel
- Insulator Material: Thermoplastic, UL 94V-0 rated
- Insulator Color: Black
- Contact Type: Solder pot
- Contact Material: Copper alloy
- Contact Finish: Gold flash (Performance Class 3)
- Mounting Method: 120 inches (3.05 mm) Through Hole
Buy the Cannon Series COMBO D DSub: DDM24W7PK87
Purchase the Cannon Series COMBO D DDM24W7PK87 online today for reliable and durable connections suited for computer and peripheral devices. Designed with solder pot contacts, a thermoplastic insulator, and a steel shell with tin finish, this connector supports wire sizes from 8 to 26 AWG, delivering a maximum current of 7.5A with excellent resistance. Its operating temperature range from -55°C to +125°C ensures performance in diverse environments. Invest now for high-quality connectivity solutions that meet your technical needs and offer long-lasting durability.
Order your Cannon Series COMBO D DDM24W7PK87 today and ensure dependable, robust connections for your computer and peripheral applications.
Frequently Asked Questions
Where can I buy ITT CANNON DDM24W7PK87?
You can click on the BUY or RFQ button to purchase DDM24W7PK87 from an authorized ITT CANNON distributor.
How do I troubleshoot issues or seek technical support for part DDM24W7PK87?
You can download the DDM24W7PK87 datasheet or visit the ITT CANNON website for support.
Who is the manufacturer of DDM24W7PK87?
ITT CANNON
