ITT CANNON DDMM36W4S D-Subminiature Connector
The Cannon Combo D Series D-Subminiature connector offers a reliable connection solution for a wide range of electronic applications. It features 36W4 contact arrangement with 32 contacts of size 20 and 4 empty cavities, supporting wire gauges from AWG 8 to 26. With a dielectric withstand voltage of 500 VAC at sea level and a current rating of 7.5 A for signal contacts, it ensures robust performance in harsh environments. The shell, made of steel with yellow chromate over zinc finish, provides durability, while the thermoplastic insulator and gold-over-nickel contacts ensure excellent conductivity and corrosion resistance. Suitable for high-reliability industrial, automation, and electronic systems requiring up to 500 mating cycles, operating from -55°C to +150°C. This versatile D-Sub connector is designed for solder pot contact type and through-hole mounting, making it ideal for secure connections and long-lasting durability in demanding applications.
ITT CANNON DDMM36W4S D-Subminiature Connector Specifications:
- Contact Arrangement: 36W4 (32 contacts size 20, 4 empty cavities)
- Wire Gauge Range: AWG 8-26
- Mating Cycles: 500
- Dielectric Withstanding Voltage: 500 VAC at sea level
- Current Rating: 7.5 A max
- Contact Resistance: 10 milli Ohm max
- Operating Temperature: -55°C to +150°C
- Shell Material: Steel with yellow chromate over zinc finish
- Insulator Material: Thermoplastic, UL 94V-0
- Contact Material: Copper alloy
- Contact Finish: Gold over nickel
- Mounting Method: 120-inch (3.05 mm) through-hole
- Salt Spray Test Duration: 48 hours, or 96 hours for stainless steel
- Contact Type: Solder pot
Buy the Buy Cannon D Sub Series Combo D Part Number DDMM36W4S Online
Purchase the Cannon D Series Combo D Connector online today for a durable, high-performance connection solution ideal for industrial automation, aerospace, and electronics. Designed for harsh environments, it features a steel shell with yellow chromate over zinc, 36W4 contact arrangement, and gold-over-nickel contacts ensuring excellent conductivity and corrosion resistance. Its operating temperature range from -55°C to +150°C supports diverse applications requiring high reliability and long-lasting service. Secure your electronic systems with this reliable, industry-standard D-Sub connector, available for quick online ordering and fast delivery.
Get Cannon D Sub Series Combo D PartNumber DDMM36W4S today—designed for durability, high performance, and reliable electronic connections in demanding environments.
Frequently Asked Questions
Where can I buy ITT CANNON DDMM36W4S?
You can click on the BUY or RFQ button to purchase DDMM36W4S from an authorized ITT CANNON distributor.
How do I troubleshoot issues or seek technical support for part DDMM36W4S?
You can download the DDMM36W4S datasheet or visit the ITT CANNON website for support.
Who is the manufacturer of DDMM36W4S?
ITT CANNON
