ITT CANNON DL1156RW6B Receptacle
The DL1-156RW-6B is a 6-way through-hole receptacle featuring gold flash copper alloy contacts, a black glass-filled thermoplastic insulator, and single-hand actuation. The DL series Zero Insertion Force connector can be mated and unmated in less than 2 seconds and accepts wire ranges from 42 to 18 AWG. It offers an insulation resistance of 5000 MΩ, operates within a temperature range of -55°C to +105°C, and has a UL94V-1 flammability rating. Suitable for industrial, medical, commercial, and computer applications.
ITT CANNON DL1156RW6B Receptacle Specifications:
- Contact Material: Copper alloy, gold flash over nickel
- Insulator Material: Glass filled thermoplastic, UL 94V-1 rated, Color: Black
- Number of Contacts: 6 positions
- Contact Type: Through-hole, PC/RC
- Wire Range: 42-18 AWG
- Insulation Resistance: 5000 MΩ minimum
- Dielectric Withstanding Voltage: 1200 VAC RMS
- Operating Temperature: -55°C to +105°C
- Flammability Rating: UL 94V-1
- Mating/Unmating Cycles: Minimum 10,000 cycles
- Contact Resistance: Max 30 mΩ
- Contact Retention Force: Minimum 8 lbs (35.6 N)
Buy the Cannon Series DL Receptacle: DL1-156RW6B
Order the Cannon DL1-156RW6B receptacle online today and enjoy quick delivery of a reliable, high-performance connector. Designed for demanding industrial, medical, and computer systems, this 6-position, gold contact, thermoplastic insulator connector allows fast, low-force mating in various environments. Its robust design supports up to 20,000 mating cycles, with excellent electrical performance. Perfect for applications requiring secure, high-quality connections with simple installation and superior durability. Enhance your project efficiency—buy now and ensure dependable connectivity.
Buy Cannon DL1-156RW6B now and experience unmatched reliability and performance for industrial and medical applications.
Frequently Asked Questions
Where can I buy ITT CANNON DL1156RW6B?
You can click on the BUY or RFQ button to purchase DL1156RW6B from an authorized ITT CANNON distributor.
How do I troubleshoot issues or seek technical support for part DL1156RW6B?
You can download the DL1156RW6B datasheet or visit the ITT CANNON website for support.
Who is the manufacturer of DL1156RW6B?
ITT CANNON
