ITT CANNON KPSE06F1210S Industrial Circular Connector
The KPSE06F1210S is a high-performance, MIL-DTL-26482 Series I equivalent straight plug connector from the KPSE series by ITT Cannon. It features a quick-release bayonet coupling, five keyway polarization, and high contact density with 10 contacts. Designed for harsh environments, this environmentally sealed connector (IP68 rated) withstands extreme shock, vibration, and exposure, making it suitable for industrial and commercial applications. It operates within -55°C to +125°C, supports up to 500 mating cycles, and maintains 5000 MΩ insulation resistance at 25°C. Constructed with an aluminum alloy body with olive drab chromate over cadmium plating, and gold-plated copper alloy crimp contacts, it offers reliable, durable performance, easy clip-in contact, and quick assembly, ensuring interchangeability with all MIL-DTL-26482 connectors and options for cost-effective design modifications.
ITT CANNON KPSE06F1210S Industrial Circular Connector Specifications:
- Shell Material: Aluminium alloy with olive drab chromate over cadmium plating
- Contact Plating: Copper alloy, gold plated
- Number of contacts: 10
- Contact Type: Crimp contacts
- Operating Temperature: -55°C to +125°C
- Water Tightness: IP68, withstands 0.2 bar pressure over 48 hours
- Vibration Resistance: 200 m/s² at 10 to 2000 Hz
- Mating Cycles: 500 minimum
- Contact Rating: 7.5A at AWG20
- Insulator Resistance: 5000 MΩ
- Test Voltage: 1500 V RMS
- Shell Size: 12
- Shell Style: Straight plug
- Endbell Style: Grommet seal with strain relief
- Gender: Socket
- Dimensions: Not specified
- Certifications: IP67 and IP68 rated according to DIN 40 050, VG95319
Buy the Cannon KPSE06F1210S – Reliable Industrial Connectors for Harsh Environments
Purchase the Cannon KPSE06F1210S cylindrical connector online today for high durability and reliable performance in demanding environments. Perfect for industrial automation, military, and harsh industrial applications, this high-quality connector features IP68 sealing, a rugged aluminum alloy body, gold-plated contacts, and supports over 500 mating cycles. Its quick connection bayonet coupling ensures easy assembly and interchangeability. Get your reliable, waterproof connector now for a durable, high-performance solution suitable for extreme shock, vibration, and temperature variations, ensuring seamless operation in critical industrial systems.
Order your Cannon Series KPSE06F1210S today and give your projects the dependable sealing and rugged performance they require for industrial use.
Frequently Asked Questions
Where can I buy ITT CANNON KPSE06F1210S?
You can click on the BUY or RFQ button to purchase KPSE06F1210S from an authorized ITT CANNON distributor.
How do I troubleshoot issues or seek technical support for part KPSE06F1210S?
You can download the KPSE06F1210S datasheet or visit the ITT CANNON website for support.
Who is the manufacturer of KPSE06F1210S?
ITT CANNON
