ITT CANNON KPT06B1419P Circular Connector
The KPT06B14-19P from ITT Cannon is a high-performance circular connector in the KPT series, featuring 19 gold-plated contacts within a durable aluminum alloy shell. Designed for demanding environments, it offers IP67 sealing, resistance to vibration and shock, and a temperature range of -55°C to +125°C. This connector is easy to assemble with clip-in contacts, ensuring quick installation. It withstands 500 mating cycles and environmental conditions like salt spray for 500 hours. Ideal for industrial, military, and harsh-condition applications requiring reliable, high-density connections with high electrical performance and environmental sealing.
ITT CANNON KPT06B1419P Circular Connector Specifications:
- Shell Material: Aluminium alloy with olive drab chromate over cadmium plating
- Contact Material: Copper alloy with gold plating
- Number of contacts: 19
- Contact Type: Solder Cup
- Water Tightness: IP67 (DIN 40 050, 0.2 bar pressure over 48 hrs)
- Operating Temperature: -55°C to +125°C
- Vibration Resistance: 200 m/s² at 10 to 2000 Hz
- Mating Cycles: 500 min
- Insulation Resistance: 5000 MΩ at 25°C
- Test Voltage: 1500 V rms
- Seal: Environmentally sealed, resistant to salt spray for 500 hours
- Connector Style: Straight plug, general duty with strain relief
- Gender: Pin, shell size 14
- Contact Rating: 7.5 A (AWG20)
- Operating Voltage: In accordance with DIN VDE 410, IEC 60364-4-41
Buy the Cannon Series KPT MIL-DTL-26482 Straight Plug Connector: KPT06B14-19P
Order the Cannon KPT06B14-19P circular connector online today to ensure robust, waterproof, and vibration-resistant connections for your industrial or military applications. This high-quality connector features 19 gold-plated contacts, a durable aluminum shell, and environmental sealing for IP67 protection. Designed for quick assembly with clip-in contacts, it withstands extreme temperatures from -55°C to +125°C, offers 500 mating cycles, and resists corrosion and salt spray for long-lasting reliability. Ideal for demanding environments requiring secure and high-performance electrical connections, available now for immediate purchase.
Buy Cannon KPT06B14-19P now and experience unmatched reliability and performance for harsh environmental conditions.
