ITT CANNON KPT06F1418P MIL-DTL-26482 Connector
The KPT06F14-18P from ITT Cannon is a rugged, MIL-DTL-26482 Series I compliant straight plug connector with 18 contacts designed for harsh environments. It features a bayonet quick disconnect, positive three-point coupling, and five keyway polarization, providing secure and reliable connections. Built with an aluminum alloy shell, olive drab chromate over cadmium plating, and copper alloy contacts with gold plating, it offers excellent durability. Rated for -55°C to +125°C, with resistance to vibration, shock, and water ingress, it supports up to 500 mating cycles, making it ideal for industrial and military applications demanding durable, high-performance connectors.
ITT CANNON KPT06F1418P MIL-DTL-26482 Connector Specifications:
- Shell Style: Straight plug
- Shell Material: Aluminium alloy with olive drab chromate over cadmium plating
- Contact Arrangement: 14-18 positions
- Number of contacts: 18 contacts, size 20
- Contact Type: Solder cup, gold plated
- Operating Temperature: -55°C to +125°C
- Water Tightness: IP67, tested to DIN 40 050 with 0.2 bar pressure over 48 hrs
- Vibration resistance: 200 m/s² at 10 to 2000 Hz
- Insulation Resistance: 5000 MΩ at 25°C
- Test Voltage: 1500 V rms
- Mating Cycles: Minimum 500
- Operating Voltage: In accordance with DIN VDE 410 and IEC 60364-4-41
- Certifications: Complies with VG95319 and VG95210 for tests and durability
Buy the ITT Circular KPT06F14-18P – Reliable MIL-DTL-26482 Connectors for Industrial Applications
Choose the ITT Cannon KPT06F14-18P connector for robust industrial and military applications needing water resistance, vibration tolerance, and high durability. This connector features 18 gold-plated solder cup contacts housed in an aluminum alloy shell with an IP67 rating, ensuring water ingress protection. It operates across a broad temperature range from -55°C to +125°C, supporting at least 500 mating cycles. Its design withstands extreme shock and vibration, making it ideal for harsh operational environments. Purchase online today for reliable, durable, and easy-to-install electrical connections in demanding settings.
Order your ITT KPT06F14-18P series connector today and ensure your projects benefit from the rugged, high-performance connection reliability essential in challenging environments.
Frequently Asked Questions
Where can I buy ITT CANNON KPT06F1418P?
You can click on the BUY or RFQ button to purchase KPT06F1418P from an authorized ITT CANNON distributor.
How do I troubleshoot issues or seek technical support for part KPT06F1418P?
You can download the KPT06F1418P datasheet or visit the ITT CANNON website for support.
Who is the manufacturer of KPT06F1418P?
ITT CANNON
