ITT CANNON MDM15PH006B Micro D Connector
The MDM-15PH006B is a compact, 15-way micro D crimp cable plug with gold-plated copper contacts. Its durable aluminum shell with yellow chromate/cadmium over nickel finish ensures environmental resistance and EMI shielding. Designed for high reliability, it supports an operating temperature from -55°C to +125°C, making it ideal for demanding industrial environments. This connector features a friction coupling mechanism, a maximum current rating of 3A, and complies with dielectric voltage withstand standards. Suitable for applications requiring durable, high-performance connections in compact spaces.
ITT CANNON MDM15PH006B Micro D Connector Specifications:
- Contact Material: Gold-plated copper alloy
- Contact Arrangement: 15 pins
- Shell Material: Aluminum
- Shell Finish: Yellow Chromate/Cadmium over Nickel
- Termination Type: Crimp, 36" length, #26AWG, colored code
- Current Rating: 3A
- Dielectric Withstanding Voltage: 600 VAC at sea level, 150 VAC at 70,000 feet
- Insulator Material: Liquid crystalline polymer (contact size 9-100), Diallyl phthalate (7C2 or 24C4 contacts)
- Hardware: B .092 diameter mounting holes
- Coupling: Friction
- Temperature Range: -55°C to +125°C
- Insulator Resistance: >100 megohms
- Insulation Resistance: 5000 megohms min.
- Durability: 500 mating cycles
- Vibration Resistance: 20G's, 10-2000 Hz, 12 hours
- Seal: Salt spray resistance for 48 hours
- Shock Resistance: 50 G's in 3 axes, 6 ms pulse
Buy the Cannon MDM-15PHO06B – Reliable Micro D Connectors for Industrial Applications
Secure your industrial connections today by purchasing the Cannon MDM-15PHO06B Micro D connector online. This reliable, corrosion-resistant, lightweight connector is designed for demanding environments, offering excellent EMI shielding, high durability, and temperature resilience. Perfect for automation, robotics, and control systems, it guarantees high performance in tight spaces and harsh conditions. Easy to install, it supports multiple mating cycles and maintains excellent electrical resistance, making it the ideal choice for professional engineers and technicians seeking quality components for advanced industrial applications.
Order your Cannon MDM-15PHO06B series micro D crimp connector today and ensure your industrial projects benefit from durable, high-performance connections.
Frequently Asked Questions
Where can I buy ITT CANNON MDM15PH006B?
You can click on the BUY or RFQ button to purchase MDM15PH006B from an authorized ITT CANNON distributor.
How do I troubleshoot issues or seek technical support for part MDM15PH006B?
You can download the MDM15PH006B datasheet or visit the ITT CANNON website for support.
Who is the manufacturer of MDM15PH006B?
ITT CANNON
