ITT CANNON MDM9PSB Micro D Connector
The MDM-9PSB is a 9-way solder plug connector featuring gold-plated copper contacts that accept 26 AWG wire. Designed with a lightweight Micro D metal shell, it offers high performance, durability, and environmental protection. Suitable for demanding industrial applications, it provides excellent EMI and RFI shielding, ensuring reliable signal integrity. The connector operates efficiently within a temperature range of -55°C to +125°C, with robust resistance to thermal shock, vibration, moisture, and salt spray. Its compact design and friction coupling make it ideal for numerous high-reliability electronic and industrial uses.
ITT CANNON MDM9PSB Micro D Connector Specifications:
- Contact Material: gold plated copper alloy
- Contact Resistance: 8 milliohms max
- Termination Type: solder pot for #26AWG wire
- Shell Material: aluminum
- Shell Finish: yellow chromate/cadmium over nickel
- Insulator Material: liquid crystalline polymer or Diallyl phthalate
- Current Rating: 3A max
- Dielectric Withstanding Voltage: 600 VAC at sea level, 150 VAC at 70,000 ft altitude
- Insulator Resistance: 5000 megohms min
- Thermal Shock Resistance: -55°C to +125°C
- Physical Shock: 50 G's, 3 axes, 6 ms sawtooth pulse
- Vibration: 20 G's, 10-2000 Hz, 12 hours
- Durability: 500 mating cycles
- Moisture Resistance: insulator resistance > 100 megohms
- Salt Spray Resistance: 48 hours
Buy the Cannon MDM-9PSB – Reliable Micro Connector for Industrial Applications
Purchase the Cannon MDM-9PSB Micro D connector online today for high-quality, reliable performance in industrial and electronic applications. Featuring gold-plated contacts, a durable aluminum shell, and a compact, lightweight design, this connector is excellent for harsh environments. It supports 26 AWG wire with solder pot termination, operates from -55°C to +125°C, and provides superior EMI/RFI shielding. Its high resistance to thermal shock, vibration, moisture, and salt spray makes it ideal for demanding projects requiring dependable, long-lasting connections. Order now for fast delivery and competitive pricing.
Order your Cannon MDM-9PSB series high-performance solder plug connector today and ensure secure, durable connections in demanding industrial environments.
Frequently Asked Questions
Where can I buy ITT CANNON MDM9PSB?
You can click on the BUY or RFQ button to purchase MDM9PSB from an authorized ITT CANNON distributor.
How do I troubleshoot issues or seek technical support for part MDM9PSB?
You can download the MDM9PSB datasheet or visit the ITT CANNON website for support.
Who is the manufacturer of MDM9PSB?
ITT CANNON
