ITT CANNON MS3101E2029PF187 MIL-C-5015 Receptacle
The MIL-DTL-5015 series cable mount receptacle is designed for high durability and reliability in demanding environments. It features 17 contacts and is constructed from aluminum alloy with olive drab chromate over cadmium plating. The connector offers quick threaded coupling, environmental sealing with IP67 protection, and is resistant to moisture and corrosion. It is capable of withstanding extreme temperatures from -55°C to +125°C, with a minimum insulation resistance of 5000 MΩ at 25°C. Suitable for defense, military, aerospace, and industrial applications, it provides high-density contact arrangements in a compact, lightweight design with various shell styles, sizes, and polarization features.
ITT CANNON MS3101E2029PF187 MIL-C-5015 Receptacle Specifications:
- Shell Material: Aluminum Alloy
- Finish: Olive Drab Chromate over Cadmium
- Contacts: 17, silver plated copper alloy
- Temperature Range: -55°C to +125°C
- Insulation Resistance: ≥ 5000 MΩ at 25°C
- Vibration Resistance: Meets MIL-STD-810
- Waterproof Rating: IP67
- Durability: Up to 500 mating cycles
- Shell Sizes: Various, including 85, 105, 125, 145, 165, 18, 20, 24, 28, 32, 36, 40
- Configuration: Single key/keyway polarization, multiple contact arrangements
- Application: Defense, military, aerospace, industrial sectors
- Coupling Mechanism: Quick threaded
- Environmental: Moisture, corrosion, extreme temperatures
Buy the ITT Cannon Series MIL-C-5015 Receptacle: MS3101E2029PF187
Purchase the MIL-C-5015 series cable mount receptacle MS3101E2029PF187 online today. Designed for high reliability in harsh environments, this aluminum alloy connector offers 17 contacts, IP67 sealing, and operates from -55°C to +125°C. It withstands up to 500 mating cycles, resisting moisture, corrosion, and vibration. Ideal for military, aerospace, and industrial applications, its compact and lightweight design features multiple shell sizes and configurations, ensuring secure connection and ease of installation in critical systems.
Get ITT Cannon MIL-C-5015 receptacle MS3101E2029PF187 today—built for durability, environmental sealing, and high-performance applications in demanding environments.
Frequently Asked Questions
Where can I buy ITT CANNON MS3101E2029PF187?
You can click on the BUY or RFQ button to purchase MS3101E2029PF187 from an authorized ITT CANNON distributor.
How do I troubleshoot issues or seek technical support for part MS3101E2029PF187?
You can download the MS3101E2029PF187 datasheet or visit the ITT CANNON website for support.
Who is the manufacturer of MS3101E2029PF187?
ITT CANNON
