ITT CANNON MS3102R2222S MIL-DTL-5015 Circular Connector
The ITT Cannon MS3102R22-22S is a MIL-DTL-5015 series box mount receptacle with four solder cup contacts, constructed from durable aluminum alloy with olive drab chromate over cadmium plating. Designed for harsh environments, it withstands extreme temperatures from -55°C to +125°C, offers IP65 sealing, and is salt spray resistant for 500 hours. The connector features a threaded coupling mechanism for secure locking, supports 500 mating cycles, and has a contact rating suitable for high-current applications. It is ideal for military, aerospace, industrial, and defense use, ensuring reliable, robust connectivity in demanding conditions.
ITT CANNON MS3102R2222S MIL-DTL-5015 Circular Connector Specifications:
- Shell Material: Aluminum alloy with olive drab chromate coating over cadmium plating
- Shell Style: Box mounting receptacle
- Shell Size: 22
- Contact Arrangement: 22-22, 4 contacts size 8
- Contact Type: Solder Cup
- Contact Plating: Hard silver
- Number of Contacts: 4
- Operating Temperature: -55°C to +125°C
- Contact Resistance: 1mΩ at +20°C
- Insulator Resistance: >1000 MΩ
- Test Voltage: 1600 Vrms
- Environmental Resistance: Salt spray resistant for 500 hours
- Ingress Protection: IP65
- Mating Cycles: 500
- Coupling Torque: Max 11 Nm (closing), Min 0.8 Nm (opening)
- Shell Material: Aluminum alloy
- Gasket Material: Neoprene
- Wire Stripping Length: 11.8 mm
- Seal Min Air and Creepage Path: 41.4 mm
Buy the Buy ITT Cannon Circular Part Number MS3102R22-22S Online
Purchase the ITT Cannon Circular Connector MS3102R22-22S online today for unparalleled durability, high environmental resistance, and secure threaded coupling. Designed for extreme temperatures from -55°C to +125°C, it features four solder cup contacts with silver plating for excellent electrical performance. Its rugged aluminum shell with olive drab chromate over cadmium plating ensures durability in military, aerospace, and industrial environments. With IP65 sealing, salt spray resistance for 500 hours, and support for 500 mating cycles, this connector guarantees long-lasting, dependable performance in the most challenging conditions.
Order your ITT Cannon Series MS3102R22-22S today and secure reliable, high-performance connections suitable for demanding military and industrial applications.
Frequently Asked Questions
Where can I buy ITT CANNON MS3102R2222S?
You can click on the BUY or RFQ button to purchase MS3102R2222S from an authorized ITT CANNON distributor.
How do I troubleshoot issues or seek technical support for part MS3102R2222S?
You can download the MS3102R2222S datasheet or visit the ITT CANNON website for support.
Who is the manufacturer of MS3102R2222S?
ITT CANNON
