ITT CANNON MS3102R2222SX MIL-DTL-5015 Connector
The ITT Cannon MS3102R22-22SX is a robust MIL-DTL-5015 series connector designed for high-reliability applications in demanding environments. Constructed with a durable aluminum alloy shell topped with olive drab chromate over cadmium, it features four solder cup contacts with silver plating for excellent electrical performance. This connector supports threaded coupling for secure and quick mating, offers IP65 environmental sealing, and operates efficiently within -55°C to +125°C temperatures. Suitable for aerospace, military, and industrial use, it withstands harsh conditions including moisture, corrosion, shock, and vibration, with a rated lifespan of 500 mating cycles.
ITT CANNON MS3102R2222SX MIL-DTL-5015 Connector Specifications:
- Shell Material: Aluminum alloy with olive drab chromate over cadmium plating
- Number of contacts: 4
- Contact Type: Solder Cup
- Contact Plating: Hard silver
- Shell Size: 22
- Mounting Style: Box
- Operating Temperature: -55°C to +125°C
- Ingress Protection: IP65
- Salt Spray Resistance: 500 hours
- Mating Cycles: 500
- Coupling Torque: 11 Nm max (closing), 0.8 Nm min (opening)
- Contact Retention Force: 80 N
- Test Voltage: 1600 Vrms
- Insulator Resistance: > 1000 MO at standard conditions
- Air and Creepage Paths: Min 4.4mm
- Seal: Environmental sealing to IP65
- Insulation Material: Neoprene
- Grommet Material: Neoprene
Buy the Cannon Series MIL-C-5015 MIL-DTL 5015 Connector: MS3102R22-22SX
Purchase the Cannon MS3102R22-22SX online today and benefit from a highly durable, environmentally sealed connector designed for aerospace, military, and industrial applications. Featuring a compact box mount design with four solder cup contacts, this connector provides excellent electrical performance and resilience against moisture, corrosion, and vibration. Its threaded coupling ensures quick, secure mating, while its IP65 rating offers protection against harsh environmental elements. Ideal for demanding operational conditions, this connector supports up to 500 mating cycles and operates from -55°C to +125°C for versatile use.
Buy Cannon MS3102R22-22SX now and experience unmatched reliability and rugged performance in demanding environments.
Frequently Asked Questions
Where can I buy ITT CANNON MS3102R2222SX?
You can click on the BUY or RFQ button to purchase MS3102R2222SX from an authorized ITT CANNON distributor.
How do I troubleshoot issues or seek technical support for part MS3102R2222SX?
You can download the MS3102R2222SX datasheet or visit the ITT CANNON website for support.
Who is the manufacturer of MS3102R2222SX?
ITT CANNON
