ITT CANNON MS3106E12S3P mil-spec circular connector
The MS3106E12S-3P from ITT Cannon is a durable MIL-DTL-5015 series straight plug connector with two solder cup contacts, designed for high-performance military, aerospace, and industrial applications. Crafted from aluminum alloy with olive drab chromate over cadmium plating, it offers excellent corrosion resistance and environmental sealing rated IP65. With a salt spray resistance of up to 500 hours, it withstands harsh conditions. Its threaded coupling, operating temperature from -55°C to +125°C, and vibration and shock resistance ensure reliable performance in demanding environments. Suitable for high-density contacts in compact circular shells, the connector is built for long-lasting durability and safety.
ITT CANNON MS3106E12S3P mil-spec circular connector Specifications:
- Shell Material: Aluminum alloy with olive drab chromate over cadmium plating
- Contact Type: Solder cup, 2 contacts size 16S
- Contact Material: Copper alloy with hard silver plating
- Operating Temperature Range: -55°C to +125°C
- Salt Spray Resistance: 500 hours
- Ingress Protection: IP65 according to DIN 40 050
- Mating Cycles: 500 minimum
- Coupling Torque (Closing): 2.5 Nm max
- Shell Size: 128
- Gender: Pin
- Endbell Style: With clamp and bushing
- Connector Style: Shell style plug, straight
- Insulator and Grommet Material: Neoprene
- Wire Stripping Length: 6.2 mm
- Test Voltage: 1600 Vrms
- Air and Creepage Paths (Min): 1.4mm
- Ambient Temperature Range: -55°C to +125°C
Buy the ITT Series MIL-DTL 5015 MIL-C-5015 Connector: MS3106E12S3P
Discover the ITT Cannon MS3106E12S3P MIL-DTL-5015 series connector, engineered for demanding applications requiring high durability, corrosion resistance, and environmental sealing. Featuring a rugged aluminum shell with olive drab chromate over cadmium plating, this connector offers superior salt spray resistance for up to 500 hours, ensuring longevity in harsh conditions. Its compact design with high-density contacts and threaded coupling allows quick mating and secure connection. Ideal for aerospace, military, and industrial systems, this connector guarantees reliable operation across a temperature range from -55°C to +125°C, making it an essential component for mission-critical environments.
Get ITT Cannon MS3106E12S3P today—built for high durability and reliable performance in harsh environments with corrosion and vibration resistance.
Frequently Asked Questions
Where can I buy ITT CANNON MS3106E12S3P?
You can click on the BUY or RFQ button to purchase MS3106E12S3P from an authorized ITT CANNON distributor.
How do I troubleshoot issues or seek technical support for part MS3106E12S3P?
You can download the MS3106E12S3P datasheet or visit the ITT CANNON website for support.
Who is the manufacturer of MS3106E12S3P?
ITT CANNON
