ITT CANNON MS3106F181P Circular Connector
The MS3106F18-1P from ITT Cannon is a MIL-DTL-5015 series straight plug connector featuring 10 contacts. This high-reliability connector is designed with a military-grade circular shell available in five styles and 19 sizes. It offers single key/keyway polarization, environmental sealing, and is resistant to moisture and corrosion. Constructed from aluminum alloy with olive drab chromate over cadmium plating, and brass or copper alloy solder pin contacts with silver plating, it supports up to 500 mating cycles and operates in extreme temperatures from -55°C to +125°C. The connector provides quick threaded coupling, IP67 environmental protection, and is suitable for defense, military, aerospace, and industrial applications.
ITT CANNON MS3106F181P Circular Connector Specifications:
- Shell Material: Aluminum alloy with olive drab chromate over cadmium plating
- Contact Material: Copper alloy with silver plating
- Number of Contacts: 10
- Contact Size: 16
- Contact Type: Solder cup
- Operating Temperature Range: -55°C to +125°C
- Mating Cycles: 500
- External Shell Style: Straight plug with threaded coupling
- Environmental Protection: IP67 rated, salt spray resistant for 500 hours
- Seal: Environmental sealing standard compliance
- Insulator Resistance: > 1000 MO
- Test Voltage: 1600 Vrms
- Air and Creepage Paths: Min 1.4 mm
- Coupling Torque: Closing 8 Nm max, Opening 0.58 Nm min
- Insulator Diameter: See assembly instructions
- Wire Stripping Length: 6.2 mm
Buy the Buy ITT Cannon Circular Connector Part Number MS3106F18-1P Online
Purchase the ITT Cannon Circular Connector MS3106F18-1P online today for reliable performance in demanding military, aerospace, and industrial environments. Designed for high durability, it features 10 solder cup contacts, corrosion-resistant aluminum shell, and supports up to 500 mating cycles. Its environmental sealing ensures protection against moisture, dust, and salt spray, meeting strict military standards. Perfect for applications requiring rugged, quick-connect solutions in extreme temperatures from -55°C to +125°C, this connector guarantees long-term performance and secure electrical connections. Order now for fast delivery and quality assurance.
Get ITT Cannon MS3106F18-1P today—robust MIL-DTL-5015 connector built for precision, environmental sealing, and long-lasting durability in extreme conditions.
