ITT CANNON MS3106F2033P Circular Connector
The MS3106F20-33P is a rugged, high-reliability circular connector designed for industrial and aerospace applications. Featuring a straight shell style and threaded coupling, it offers durability with aluminum alloy shell plating in olive drab chromate over cadmium. The connector supports 14 solder cup contacts, rated for high-performance operation up to 125°C. It is IP65 rated for environmental protection, salt spray resistant for 500 hours, and withstands 500 mating cycles, making it ideal for harsh conditions. The connector covers sizes 15, 15S, 16, and 16S with a contact resistance of aan and safety provisions for voltages above 50V.
ITT CANNON MS3106F2033P Circular Connector Specifications:
- Shell Material: Aluminum alloy
- Shell Plating: Olive drab chromate over cadmium
- Contact Type: Solder cup
- Number of Contacts: 14
- Contact Size: 16
- Contact Plating: Hard silver
- Operating Temperature: -55°C to +125°C
- Ingress Protection: IP65
- Salt Spray Resistance: 500 hours
- Mating Cycles: 500 minimum
- Cable Stripping Length: 6.2 mm
- Test Voltage: 1600 Vrms
- Air and Creepage Paths: 1.4 mm
- Coupling Torque: Closing 9 Nm max, Opening 0.7 Nm min
- Insulator Resistance: >1000 MΩ
- Ambient Temperature Range: -67°F to 257°F
Buy the Buy Cannon Circular Connectors Part Number MS3106F20-33P Online
Purchase the Cannon MS3106F20-33P circular connector online today for high durability, environmental resistance, and reliable electrical connections in demanding industrial and aerospace environments. This connector features 14 solder cup contacts, IP65 ingress protection, salt spray resistance for 500 hours, and supports 500 mating cycles, ensuring long-term performance and safety in harsh conditions. Easy to install with a robust aluminum alloy shell, olive drab chromate coating, and neoprene insulator, it guarantees secure connections, withstands extreme temperatures, and meets all safety standards for high voltage applications.
Get Cannon MS3106F20-33P today—built for harsh environments, high reliability, and long-lasting durability in industrial and aerospace applications.
Frequently Asked Questions
Where can I buy ITT CANNON MS3106F2033P?
You can click on the BUY or RFQ button to purchase MS3106F2033P from an authorized ITT CANNON distributor.
How do I troubleshoot issues or seek technical support for part MS3106F2033P?
You can download the MS3106F2033P datasheet or visit the ITT CANNON website for support.
Who is the manufacturer of MS3106F2033P?
ITT CANNON
