ITT CANNON MS3106F2411P Circular Connector
The MS3106F24-11P is a durable, high-quality circular connector designed for military and industrial applications. Featuring a shell size 24, three contact sizes, and a solder cup contact type, it provides reliable electrical connections with hard silver plating. The connector boasts IP65 sealing, salt spray resistance for 500 hours, and a maximum operating voltage in accordance with international standards. Its aluminium alloy shell is coated with olive drab chromate, ensuring corrosion resistance suitable for harsh environments. Designed for 500 mating cycles, it is ideal for aerospace, military, and automation systems requiring rugged reliability.
ITT CANNON MS3106F2411P Circular Connector Specifications:
- Shell Size: 24
- Contact Arrangement: 24-11
- Number of Contacts: 3 size 8, 6 size 12
- Contact Type: Solder Cup
- Contact Plating: Hard silver
- Shell Material: Aluminium alloy
- Shell Coating: Olive drab chromate over cadmium plating
- Insulator Material: Neoprene
- Operating Voltage: in accordance with DIN VDE V 410 and IEC 60364-4-41 for voltages >50V
- Insulator Resistance: > 1000 MO
- Test Voltage: 1600 Vrms
- Air and Creepage Path: Min 1.4mm
- Ambient Temperature Range: -55°C to +125°C
- Protection Class: IP65 according to DIN 40 050
- Salt Spray Resistance: 500 hours
- Mating Cycles: 500 minimum
- Separate Forces: 1.5 N per contact (size 25/12), 3.0 N per contact (size 60/100/8)
- Coupling Torque: Max 14 Nm (closing), Min 0.8 Nm (opening)
- Contact Retention: 55 N (size 25/12), 80 N (size 60/100/8)
Buy the Cannon Series MIL-C-5015 MIL-DTL 5015 Circular Connector: MS3106F24-11P
Discover the durable and reliable MS3106F24-11P circular connector from Cannon, designed for harsh environments with IP65 sealing, salt spray resistance, and high durability. This connector is ideal for aerospace, military, and industrial automation systems, providing excellent electrical connections with a maximum of 500 mating cycles. Its aluminium alloy shell coated in olive drab chromate ensures corrosion resistance, while its solder cup contacts guarantee secure connections. Trust this high-performance connector for your critical applications requiring rugged reliability and compliance with industrial standards.
Order your Cannon Series MIL-C-5015 MS3106F24-11P connector today and ensure reliable, rugged connections for demanding industrial and military projects.
