ITT CANNON MS3112E2024P Military Receptacle Connector
The MS3112E20-24P from ITT Cannon is a MIL-DTL-26482 Series I box mount receptacle with 24 contacts, designed for high-reliability military and industrial applications. It features a self-locking three-point bayonet coupling for quick and secure mating, with precise alignment provided by five keyways. The connector is environmentally sealed, capable of withstanding extreme conditions such as shock, vibration, and exposure to harsh environments, including salt spray for 48 hours per MIL-STD-1344 standards. Made from aluminum alloy with olive drab chromate over cadmium plating, it includes copper alloy solder pin contacts with gold plating, and a resilient polychlorprene insulator and grommet. It operates across a temperature range of -55°C to +125°C, with an insulation resistance of 5000 MΩ at 25°C, and supports up to 500 mating cycles at an operating voltage of 1000VAC.
ITT CANNON MS3112E2024P Military Receptacle Connector Specifications:
- Shell Material: Aluminum alloy with olive drab chromate over cadmium plating
- Contacts: Copper alloy, gold plated
- Number of contacts: 24
- Operating voltage: Up to 1000 VAC
- Temperature range: -55°C to +125°C
- Insulation resistance: 5000 MΩ at 25°C
- Shock and vibration: MIL standards, withstands harsh conditions
- Salt spray: Capable of withstanding 48 hours in salt spray (MIL-STD-1344)
- Mating cycles: Supports up to 500
- Coupling mechanism: Self-locking three-point bayonet with five keyways
- Material finish: Olive drab chromate over cadmium
- Application: Military and industrial high-reliability environments
Buy the Amphenol MS3112E20-24P – Reliable Military Receptacle for Industrial Applications
Enhance your military and industrial applications with the high-performance Amphenol MS3112E20-24P connector. Featuring a robust three-point bayonet coupling, environmental sealing, and gold-plated copper contacts, this connector ensures reliable performance under extreme conditions. Made from durable aluminum alloy with a corrosion-resistant finish, it withstands shock, vibration, and salt spray for up to 48 hours. Capable of supporting up to 500 mating cycles at 1000VAC, it guarantees long-lasting, secure connections for demanding environments.
Order your Amphenol MS3112E20-24P today and secure high-reliability connectivity for demanding military and industrial projects.
Frequently Asked Questions
Where can I buy ITT CANNON MS3112E2024P?
You can click on the BUY or RFQ button to purchase MS3112E2024P from an authorized ITT CANNON distributor.
How do I troubleshoot issues or seek technical support for part MS3112E2024P?
You can download the MS3112E2024P datasheet or visit the ITT CANNON website for support.
Who is the manufacturer of MS3112E2024P?
ITT CANNON
