ITT CANNON MS3122E2041S Electrical Receptacle Connector
The MS3122E20-41S is an ITT Cannon MIL-DTL-26482 Series I box mount receptacle with 41 contacts, designed for demanding environments. It offers high electrical reliability, resistance to shock, vibration, and harsh exposure. Features include a self-leveling bayonet coupling for quick, secure mating, precise alignment via keyways, and environmentally sealed construction. Suitable for temperatures from -55°C to +125°C, with an insulation resistance of 5000 MΩ, and capable of 500 mating cycles at 1000 VAC. Its durability is enhanced by an aluminum alloy shell with olive drab chromate plating, copper alloy gold-plated contacts, and polychloroprene insulators and grommets.
ITT CANNON MS3122E2041S Electrical Receptacle Connector Specifications:
- Shell style: Box mounting receptacle
- Number of contacts: 41
- Contact arrangement: 20-41
- Contact type: Crimp contacts, gold plated copper alloy
- Shell material: Aluminum alloy with olive drab chromate plating
- Insulator and grommet material: Polychloroprene
- Water tightness: IP67 according to DIN 40050
- Operating temperature: -55°C to +125°C
- Number of mating cycles: at least 500
- Vibration resistance: 200 m/s² at 10-2000 Hz
- Contact rating: 7.5 A for AWG20
- Insulator resistance: 5000 MΩ
- Test voltage: 1500 V rms
- Operational voltage: up to 1000 VAC
- Certifications: VG95319, VG95210
Buy the Buy Cannon MIL-DTL-26482 Part Number MS3122E20-41S Online
Secure your equipment with the Cannon MS3122E20-41S, a high-performance electrical connector designed for harsh environments. Featuring 41 gold-plated contacts, durable aluminum alloy shell with environmental sealing, and a quick bayonet coupling, this connector ensures reliable and secure connections in demanding industrial and military applications. Its wide temperature range, high vibration resistance, and IP67 sealing make it ideal for military, aerospace, or industrial uses. Order online now for dependable performance and quick delivery.
Buy Cannon MS3122E20-41S now and experience unmatched reliability, environmental sealing, and high contact density for demanding applications.
Frequently Asked Questions
Where can I buy ITT CANNON MS3122E2041S?
You can click on the BUY or RFQ button to purchase MS3122E2041S from an authorized ITT CANNON distributor.
How do I troubleshoot issues or seek technical support for part MS3122E2041S?
You can download the MS3122E2041S datasheet or visit the ITT CANNON website for support.
Who is the manufacturer of MS3122E2041S?
ITT CANNON
