ITT CANNON NLSNBLC240M40B Powerlock Circular Connector
The Cannon Veam Powerlock & Snaplock series NLS-N-BL-C 240-M40B is a high-current circular connector designed for robust electrical connections in demanding environments. Featuring a blue thermoplastic shell and a nylon pin contact, it supports a maximum current rating of 660 A and an operating voltage of 1000 Vac. With IP67 ingress protection and UL94-VO flammability rating, it ensures safety and durability. The connector's bayonet mating method and 500 mating cycles make it suitable for industrial applications requiring reliable, long-lasting connections within a temperature range of -30°C to +125°C.
ITT CANNON NLSNBLC240M40B Powerlock Circular Connector Specifications:
- Shell Material: High temperature thermoplastic
- Color: Blue
- Contact Type: 240 mm crimp
- Cable Gland: MAB cable gland for OD 22-32 mm cables
- Maximum Current Rating: 660 A
- Maximum Rated Voltage to Earth: 2KVac | 3kVDCe
- Operating Voltage: 1000Vac
- Operating Temperature Range: -30°C to +125°C
- Insulation Resistance: <5 Mohms @500Vdc
- Ingress Protection (mated): IP67
- Protection Against Electrical Shock: IP2x
- Flammability Rating: UL94-VO
- Contact Retention: Nylon Pin
- Mating Method: Bayonet
- Mating Cycles: 500
Buy the Cannon Series Powerlock Circular Connector: NLS-N-BL-C 240-M40B
Enhance your industrial setups with the Powerlock Circular Connector featuring high current capacity of 660 A and voltage support up to 1000 Vac. Designed with a durable thermoplastic shell, IP67 protection, and UL94-VO flammability rating, this connector ensures safety and longevity in tough environments. Its bayonet mating method and nylon pin contacts provide secure, reusable connections with 500 mating cycles, making it an ideal choice for reliable power distribution in industrial, construction, and automation projects. Buy online today for trusted performance.
Order your Cannon Series Powerlock NLS-N-BL-C 240-M40B today and ensure dependable high-current connections for demanding industrial applications.
Frequently Asked Questions
Where can I buy ITT CANNON NLSNBLC240M40B?
You can click on the BUY or RFQ button to purchase NLSNBLC240M40B from an authorized ITT CANNON distributor.
How do I troubleshoot issues or seek technical support for part NLSNBLC240M40B?
You can download the NLSNBLC240M40B datasheet or visit the ITT CANNON website for support.
Who is the manufacturer of NLSNBLC240M40B?
ITT CANNON
