ITT CANNON T3P16FC1LZ Circular Connector
The T3P16FC1LZ is a versatile circular connector featuring reliable sealing and robust construction suitable for industrial, transportation, and harsh environment applications. It supports a wide range of signal and power contacts, with options for crimp, PC, coax, or first mate/last break styles, accommodating wire gauges from 28 to 12 AWG. The connector conforms to IP67 standards, ensuring water-tightness and durability in extreme temperatures from -55°C to +120°C. Its lightweight thermoplastic body, nickel-plated metal coupling ring, and high-quality sealing grommets make it ideal for critical industrial, vehicular, and control systems with high current ratings up to 30 Amps per contact.
ITT CANNON T3P16FC1LZ Circular Connector Specifications:
- Shell Material: UL94V-0 thermoplastic
- Coupling Nut: Nickel-plated copper alloy
- Seals: Rubber, silicone
- Operating Voltage: Up to 250 Vac rms
- Test Voltage: 2000 Vac rms
- Current Rating: 30 Amps (Neptune Power contacts), 13 Amps (Signal contacts), 40 Amp (TNM series)
- Wire Range: 28 - 12 AWG (stamped contacts), 18 - 8 AWG (Power Neptune)
- Temperature Range: -55°C to +120°C
- Ingress Protection: IP67, submersible
- Contact Resistance: 5 milliohms initial
- Sealing Range: 1.98 mm to 3.30 mm diameter
- Mating Life: 500 cycles (machined), 200 cycles (stamped)
- Vibration: No discontinuities longer than 1 microsecond at 55 Hz
- Shock Resistance: 50g, MIL-STD-202 Method 213
- Certifications: UL, CSA, IP67
Buy the ITT Cannon Trident – Reliable T3P16FC1LZ for Industrial Applications
Get your ITT Cannon T3P16FC1LZ connector online today and enjoy superior sealing, high current capacity, and durability for harsh industrial environments. Designed with IP67 protection and supported by multiple contact styles, this connector offers reliable performance across temperature ranges from -55°C to +120°C. It supports wire gauges from 28 to 12 AWG, making it suitable for power and signal applications. Its lightweight thermoplastic body combined with a nickel-plated metal coupling nut ensures long-lasting durability and secure connections in transportation, control systems, and demanding industrial setups. Purchase now for seamless assembly and peace of mind.
Order your ITT Cannon Series T3P16FC1LZ today and ensure your industrial projects benefit from dependable, sealed, and versatile connectors.
Frequently Asked Questions
Where can I buy ITT CANNON T3P16FC1LZ?
You can click on the BUY or RFQ button to purchase T3P16FC1LZ from an authorized ITT CANNON distributor.
How do I troubleshoot issues or seek technical support for part T3P16FC1LZ?
You can download the T3P16FC1LZ datasheet or visit the ITT CANNON website for support.
Who is the manufacturer of T3P16FC1LZ?
ITT CANNON
