JST 08TPCJWPFVKD Waterproof Connector
The waterproof wire-to-wire connector is designed for reliable electrical connections in demanding environments. It features a 2.0 mm pitch, panel lock type, and Grade 7 ingress protection rated IPX7 according to IEC 60529, suitable for waterproof applications. Constructed from thermoplastic resin, it includes pre-installed silicone rubber seals, double-spring mechanisms, and housing lances to ensure secure locking and waterproof performance. Compatible with AWG #26 to #22 wires, rated at 3A and 100 V, it withstands temperatures from -55°C to +85°C, making it ideal for industrial, outdoor, and electronics applications requiring waterproof sealing and high durability.
JST 08TPCJWPFVKD Waterproof Connector Specifications:
- Pitch: 2.0 mm
- Ingress Protection: Grade 7 (IPX7 IEC 60529)
- Current Rating: 3A AC/DC
- Voltage Rating: 100 V AC/DC
- Temperature Range: -55°C to +85°C
- Contact Resistance: Initial/10 mΩ max, Environmental/15 mΩ max
- Insulation Resistance: Initial/1,000 MΩ min, Post-test/100 MΩ min
- Withstanding Voltage: 500 VAC/min
- Applicable Wire: AWG #26 to #22 (Ø1.4 to 1.7 mm insulation diameter)
- Housing Material: Thermoplastic resin, UL94V-0, natural/black
- Seal Material: Silicone rubber, with preassembled seal rings
- Panel Thickness: 1.2 mm and 2.0 mm
- Surface Roughness: Rz 1.6 μm max
- Dimension Units: Millimeters
Buy the Buy Waterproof Connector Part Number 08TP-JWPF-VKLE-D Online
Discover the reliable waterproof connector with a 2.0 mm pitch, IPX7 ingress protection, and pre-installed silicone seals. Perfect for outdoor and industrial applications, it offers secure locking, resistance to harsh environments, and compatibility with wires up to AWG #22. The robust thermoplastic housing and silicone rubber seals ensure superior waterproof performance and durability from -55°C to +85°C. Easily installable with panel thickness options of 1.2 and 2.0 mm, this connector ensures stable, corrosion-resistant connections suitable for demanding conditions. Shop online now for fast delivery and secure connections.
Buy Waterproof Connector Part Number 08TP-JWPF-VKLE-D now and experience unmatched waterproof sealing, durability, and reliable electrical connectivity.
Frequently Asked Questions
Where can I buy JST 08TPCJWPFVKD?
You can click on the BUY or RFQ button to purchase 08TPCJWPFVKD from an authorized JST distributor.
How do I troubleshoot issues or seek technical support for part 08TPCJWPFVKD?
You can download the 08TPCJWPFVKD datasheet or visit the JST website for support.
Who is the manufacturer of 08TPCJWPFVKD?
JST
