JST PADP40V1S connector housing
This 40-position connector housing features a 2.00mm pitch, suitable for free-hanging applications. It offers reliable crimp connections, a secure latch lock for fastening, and is constructed in natural color for easy identification. Designed for high-density mounting, this connector ensures stable electrical connections with optimal contact resistance and insulation resistance. Compliant with RoHS standards, it is ideal for various electronic assemblies requiring precise, durable, and space-efficient connections in industrial, consumer, and control device applications.
JST PADP40V1S connector housing Specifications:
- Pitch: 2.00mm
- Positions: 40
- Material: Copper alloy, tin-plated, in the housing; Glass-filled PBT, ULO4V-0, natural color
- Applicable wire: AWG #28 to #22
- Wire Range: 0.13~0.33 mm O.D.
- Contact Resistance: Initial value/10mΩ max
- Insulation Resistance: 1,000 MΩ min
- Withstanding Voltage: 800V AC/minute
- Temperature Range: -25°C to +85°C
- RoHS compliance: Yes
- Dimensions: Length 38.0mm, width 26.0mm (model-specific variation)
- UL Recognized: E60389
- Certification: LR20812
Buy the Buy JST Connectors Part Number PADP40V1S Online
Purchase the JST PADP40V1S connector housing online to ensure durable and high-density connections. Ideal for free-hanging applications, this 40-position, 2.00mm pitch connector offers secure latch locking and reliable crimp contacts. Made with high-quality materials, it guarantees excellent electrical performance, compliance with RoHS standards, and compatibility with AWG #28 to #22 wires. Whether for industrial or consumer electronics, ordering this connector online provides quick delivery, authenticity, and the assurance of a trusted brand for your electronic projects.
Buy JST PADP40V1S connector housing now and experience reliable crimp connections and secure fastening for space-efficient electronic assemblies.
Frequently Asked Questions
Where can I buy JST PADP40V1S?
You can click on the BUY or RFQ button to purchase PADP40V1S from an authorized JST distributor.
How do I troubleshoot issues or seek technical support for part PADP40V1S?
You can download the PADP40V1S datasheet or visit the JST website for support.
Who is the manufacturer of PADP40V1S?
JST
