JST 26FESTVKN FFC Connector
This 26-position FFC connector features a 1.25mm pitch and is designed for reliable bottom entry contact connections. Made of copper alloy with tin plating, it ensures excellent electrical conductivity and corrosion resistance. The housing is constructed from UL94V-0-rated white PBT material, offering durability and flame retardance. It supports currents up to 1.0A and voltage ratings of 200V, with a temperature range from -25°C to +85°C. Compatible with 1.2 to 1.6mm thick PC boards, this connector adheres to RoHS standards, making it suitable for compact electronic devices requiring secure flexible flat cable connections.
JST 26FESTVKN FFC Connector Specifications:
- Number of circuits: 26
- Pitch: 1.25mm
- Contact Material: Copper alloy, tin-plated
- Housing Material: PBT, UL94V-0, white
- Current rating: 1.0A
- Voltage rating: 200V
- Temperature range: -25°C to +85°C
- Insulation resistance: ≥ 1,000MΩ
- Contact resistance: Initial/20mΩ max, after environmental testing/30mΩ max
- Withstanding voltage: 500V AC/minute
- Applicable PC board thickness: 1.2 to 1.6mm
- RoHS compliant
- Suitable for through-hole mounting in right-angle configuration
- Corrosion-resistant, made for secure electrical connections
- Designed for high contact pressure and low insertion force
- Appropriate for personal computers, VCRs, and car stereo systems
Buy the Generic 26FESTVKN – Reliable FFC Connectors for Industrial Applications
Order the 26FESTVKN FFC connector today for a secure and durable flexible flat cable connection solution. Manufactured with high-quality copper alloy contacts plated with tin for excellent electrical performance, this connector guarantees reliability in compact electronic systems. Its housing made of UL94V-0-rated PBT provides durability and safety. Compatible with PC boards from 1.2 to 1.6mm thick, it supports currents up to 1.0A and withstands voltage up to 200V. Perfect for personal computers, VCRs, and car stereo systems, buy online now for fast, trusted delivery.
Buy the 26FESTVKN FFC connector now and experience dependable high-current connections for your electronic projects.
Frequently Asked Questions
Where can I buy JST 26FESTVKN?
You can click on the BUY or RFQ button to purchase 26FESTVKN from an authorized JST distributor.
How do I troubleshoot issues or seek technical support for part 26FESTVKN?
You can download the 26FESTVKN datasheet or visit the JST website for support.
Who is the manufacturer of 26FESTVKN?
JST
