JST B04PHLALFSN connector housing
This 4-position connector housing from the HL Series features a 3.96mm pitch and supports wire gauges from 22 to 18 AWG, rated at 300V. Made from UL94V-0 rated PA 66 material, it offers reliable insulation with a natural white finish and tin-plated brass contacts for excellent conductivity and corrosion resistance. Suitable for small electronic assemblies, the housing ensures secure connections with low insertion force. Ideal for industrial automation, control panels, and wiring projects requiring compact, durable, and RoHS-compliant connectors.
JST B04PHLALFSN connector housing Specifications:
- Pitch: 3.96mm
- Number of Positions: 4
- Wire Gauge: 22-18 AWG
- Voltage Rating: 300V
- Material: PA 66, UL94V-0, natural (white)
- Contact Material: Brass, tin-plated (reflow treatment)
- Housing Finish: White
- Environmental Compliance: RoHS
- Contact Resistance: Initial 7mΩ max
- Insulation Resistance: 1,000MΩ min
- Withstanding Voltage: 1,500V AC/minute
- Operating Temperature Range: -25°C to +90°C
- Applicable PC Board Thickness: 1.5 to 2.2mm
- Certifications: RoHS
Buy the Buy JST HL Series Connector Housing Part Number B04PHLALFSN Online
Purchase the JST HL Series connector housing B04PHLALFSN online for your electronic projects. This high-quality 4-position connector with a 3.96mm pitch supports 22-18 AWG wires, rated for 300V, and features a white, tin-plated brass contact design. It provides excellent insulation, low insertion force, and RoHS compliance, making it ideal for automation, control panels, and wiring systems. Secure your electronics with this durable, reliable, and compact connector housing available for quick online purchase.
Get JST B04PHLALFSN today—designed for reliable, compact, and durable electronic connections in industrial and control applications.
Frequently Asked Questions
Where can I buy JST B04PHLALFSN?
You can click on the BUY or RFQ button to purchase B04PHLALFSN from an authorized JST distributor.
How do I troubleshoot issues or seek technical support for part B04PHLALFSN?
You can download the B04PHLALFSN datasheet or visit the JST website for support.
Who is the manufacturer of B04PHLALFSN?
JST
