JST B3PVHFBBLFSN 3-Position Connector Header
This 3-position through-hole connector header features a pitch of 3.96 mm, designed to ensure reliable pin-to-board connections in electronic assemblies. Made of phosphor bronze, its tin-plated contact offers excellent electrical conductivity and durability. Compatible with various circuit configurations, it supports applications requiring a secure, low-profile connection. The header's RoHS compliance ensures environmental sustainability. Suitable for industrial electronics, automation, and manufacturing equipment, it provides a dependable solution for connecting PCBs with precise, durable, and easy-to-assemble contacts in compact electronic systems.
JST B3PVHFBBLFSN 3-Position Connector Header Specifications:
- Pitch: 3.96 mm (0.156 inches)
- Contact Material: Phosphor bronze, tin-plated (reflow treatment)
- Current Rating: 1.0A AC, DC (AWG #26)
- Voltage Rating: 50V AC, DC
- Temperature Range: -25°C to +85°C
- Contact Resistance: Initial/20m max, environmental/30m max
- Insulation Resistance: 500MΩ min.
- Withstanding Voltage: 500V AC/minute
- Applicable Wire: AWG #32 to #26
- Board Thickness: 0.6 to 1.2mm, 1.6mm
- RoHS Compliant
- Connector Type: Through-hole, top and side entry options
- Material: Glass-filled PA 66, UL94V-0, natural (ivory)
- Standards: Recognized E60389, Certified LR20812
Buy the JST Series 3Position Through-Hole Connector: B3PVHFBBLFSN
Purchase your JST 3-Position Connector Header B3PVHFBBLFSN online today. This high-quality, RoHS compliant connector features a 3.96mm pitch, durable tin-plated phosphor bronze contacts, and versatile mounting options for wiring and PCB applications. Designed for electronic assembly professionals, it guarantees reliable electrical connections with easy insertion and extraction. Perfect for industrial automation, consumer electronics, and manufacturing systems, this connector offers durability, environmental compliance, and precision, making it an essential component for your next project.
Order your JST Series 3Position Through-Hole Connector B3PVHFBBLFSN today and ensure a reliable, secure pin-to-board connection for your electronic projects.
