JST B4PVSLFSN connector header
A 4-position top entry connector header with a 3.96mm pitch, tin-plated contacts for reliable electrical connections. Designed for signal and power supply circuits in consumer electronics and industrial applications, it offers excellent current handling up to 10A, voltage rating of 250V, and temperature range from -25°C to +85°C. Compatible with AWG #22 to #16 wires, it features a sturdy, RoHS-compliant construction, ensuring durability and safety while providing easy connection and disconnection. Suitable for PCB mounting with multiple configurations for optimized circuit design.
JST B4PVSLFSN connector header Specifications:
- Current rating: 10A AC, DC (AWG #16)
- Voltage rating: 250V AC, DC
- Temperature range: -25°C to +85°C
- Contact resistance: Initial value/ 10mΩ max, after environmental testing/ 20mΩ max
- Insulation resistance: 1,000MΩ min
- Withstanding voltage: 1,500V AC/minute
- Applicable wire: AWG #22 to #16
- Applicable PC board thickness: 1.6mm
- Material: Phosphor bronze, tin-plated (reflow treatment)
- RoHS compliant
- Dimensions: Length varies with model, typical length approximately 3.96mm, width approximately 7.86mm, height varies
- Connector type: Top entry
Buy the JST B4PVSLFSN – Reliable Connector Headers for Industrial Applications
Purchase the JST B4PVSLFSN connector online today to guarantee durable, high-performance connections for your electronic and industrial projects. This top entry connector features a 3.96mm pitch, tin-plated contacts, and a RoHS-compliant design, ensuring safety, reliability, and easy installation. Suitable for signal or power circuits with up to 10A current and 250V voltage ratings, it’s ideal for various PCB mounting applications. Secure your supply chain with this proven, versatile connector now.
Order your JST B4PVSLFSN connector today and ensure reliable, high-quality electrical connections in your industrial or electronic projects.
Frequently Asked Questions
Where can I buy JST B4PVSLFSN?
You can click on the BUY or RFQ button to purchase B4PVSLFSN from an authorized JST distributor.
How do I troubleshoot issues or seek technical support for part B4PVSLFSN?
You can download the B4PVSLFSN datasheet or visit the JST website for support.
Who is the manufacturer of B4PVSLFSN?
JST
