JST B8BPHSM4TBLFSN Connector Header
This PH series 8-position connector header features a compact 2.00mm pitch, designed for surface mount installation, offering high reliability and cost-effectiveness. It supports a voltage rating of 100V and a current capacity of 2A at DC/AC for AWG #24 wires. Made with phosphor bronze contacts, tin-plated for durability, and water-resistant PA 66 housing, it provides excellent insulation resistance of at least 1,000MΩ. The connector's modular design ensures secure connections, suitable for high-density circuit configurations, making it ideal for modern electronic devices requiring precise, space-saving connections.
JST B8BPHSM4TBLFSN Connector Header Specifications:
- Pitch: 2.00mm
- Number of Positions: 8
- Voltage Rating: 100V AC/DC
- Current Rating: 2A at DC/AC (AWG #24)
- Contact Material: Phosphor bronze, tin-plated
- Housing Material: PA 66, UL94V-0, natural (white)
- Temperature Range: -25°C to +85°C
- Water Resistance: Water-resistant housing
- Insulation Resistance: ≥1000MΩ
- Withstanding Voltage: 800V AC
- Applicable Wire: AWG #32 to #24
- Board Thickness: 0.8 to 1.6mm
- RoHS Compliant
- Mounting Type: Surface mount (SMT)
- Design: Fully shrouded header, PCB retention mechanism
Buy the Buy JST PH Series 8-Position Connector Header Part Number B8BPHSM4TBLFSN Online
Secure your electronic assemblies with the high-quality JST PH series connector header. Featuring a 2.00mm pitch, a voltage rating of 100V, and a current capacity of 2A, this surface mount connector is ideal for high-density, space-constrained applications. Crafted with tin-plated phosphor bronze contacts and water-resistant PA 66 housing, it ensures reliable connectivity and durability. Easy to install, RoHS compliant, and designed for modern electronic devices, make your purchase online today for a dependable connection solution.
Buy JST PH Series B8BPHSM4TBLFSN now and experience unmatched reliability and performance in space-saving electronic connections.
Frequently Asked Questions
Where can I buy JST B8BPHSM4TBLFSN?
You can click on the BUY or RFQ button to purchase B8BPHSM4TBLFSN from an authorized JST distributor.
How do I troubleshoot issues or seek technical support for part B8BPHSM4TBLFSN?
You can download the B8BPHSM4TBLFSN datasheet or visit the JST website for support.
Who is the manufacturer of B8BPHSM4TBLFSN?
JST
