JST BM08BSURSTFLFSN connector header
This surface mount 8-position connector header features a 0.8mm pitch, offering reliable connections for electronic assemblies. Its compact design saves space, with a side entry type occupying only 3.9mm depth and 1.75mm height after mounting, and a top entry type at 2.2mm depth and 3.9mm height. It supports wire sizes AWG #32 and #36 with tin-coated copper alloy conductors, rated for 0.5A AC/DC at 30V DC. Compliant with RoHS standards, it ensures durability and safety in electronic projects.
JST BM08BSURSTFLFSN connector header Specifications:
- Pitch: 0.8mm
- Number of positions: 8
- Current rating: 0.5A AC/DC (AWG #32), 0.2A (AWG #36)
- Voltage rating: 30V DC
- Temperature range: -25°C to +85°C
- Contact material: Copper alloy, tin-plated
- Housing material: PA, UL94V-0
- Insulation resistance: 100MΩ min
- Withstanding voltage: 200V AC/minute
- Applicable wire: AWG #32, #36, tin-coated copper, 7 strands
- Insulation O.D.: 0.39mm
- Dimensions: Side entry - 3.9mm depth, 1.75mm height; Top entry - 2.2mm depth, 3.9mm height
- Standards: RoHS compliant, Recognized E60389, Certified LR20812
Buy the Ace 02SUR-36L – Reliable Insulation Displacement Connector for Industrial Applications
Enhance your electronic projects with this high-quality 8-position surface mount connector header featuring a 0.8mm pitch. Its space-saving design allows easy installation with both side and top entry options, making it ideal for compact assemblies. Constructed with durable copper alloy contacts, tin-plated for corrosion resistance, and housed in UL94V-0 rated plastic, it offers excellent electrical performance rated for 0.5A at 30V DC. RoHS compliant, it's a reliable choice for industrial and consumer electronics, ensuring secure and efficient connectivity.
Buy Ace 02SUR-36L now and experience unmatched reliability and performance in electronic connections.
Frequently Asked Questions
Where can I buy JST BM08BSURSTFLFSN?
You can click on the BUY or RFQ button to purchase BM08BSURSTFLFSN from an authorized JST distributor.
How do I troubleshoot issues or seek technical support for part BM08BSURSTFLFSN?
You can download the BM08BSURSTFLFSN datasheet or visit the JST website for support.
Who is the manufacturer of BM08BSURSTFLFSN?
JST
