JST F32FSS03VKX Connector housings
A set of three rectangular connector housings designed as black receptacles. Each housing measures 0.200 inches (5.08 mm), suitable for electrical connections requiring precise fit and reliable contact.
JST F32FSS03VKX Connector housings Specifications:
- Pitch: 5.08 mm
- Housing Material: Glass-filled PBT, UL94V-0, black
- Contact plating: Nickel-undercoated, 0.38 um or 0.76 um selective gold-plated
- Current Rating: 18A AC/DC (for 18 circuits, AWG #14)
- Voltage Rating: 600V AC/DC
- Temperature Range: -55°C to +105°C
- Contact Resistance: Initial / 5mΩ max; After environmental testing / 10mΩ max
- Insulation Resistance: 1,000 MΩ min
- Series name: J300
- Number of circuits: 2, 4, 6, 8, 10, 12, 16, 20
- Housing: Glass-filled PBT, UL94V-0, black
- RoHS compliance: Yes
- Connector outline: Copper foil land, through-hole, compatible with standard PC boards
- Packaging: Tray or magazine stick options available
- Reinforcing metal fixture: Copper alloy, nickel-undercoated, gold or tin-plated
Buy the Buy JST J300 Series Connector Part Number F32FSS03VKX Online
Purchase the JST J300 Series connector housings today to ensure reliable electrical connections in industrial automation, signal circuits, and power applications. These durable, high-quality black connectors feature a 5.08mm pitch with superior plating options such as gold or tin for optimal conductivity. Compatible with a wide range of circuits from 2 to 20, they are designed for secure fit, easy assembly, and high-temperature resilience. Available in tray or magazine stick packaging, order now for fast delivery and efficient wiring solutions.
Buy JST J300 Series connector with 5.08mm pitch now and experience unmatched reliability and performance in industrial electrical applications.
Frequently Asked Questions
Where can I buy JST F32FSS03VKX?
You can click on the BUY or RFQ button to purchase F32FSS03VKX from an authorized JST distributor.
How do I troubleshoot issues or seek technical support for part F32FSS03VKX?
You can download the F32FSS03VKX datasheet or visit the JST website for support.
Who is the manufacturer of F32FSS03VKX?
JST
