JST PSIP03VRC Connector Socket
This PSI Series connector socket with a 4.0mm pitch offers reliable wire-to-board and wire-to-wire connections. Designed for versatility, it supports 3 circuits suitable for 26 to 16 AWG wires, ensuring secure and stable electrical connections. The connector features a dual locking system with a C keying mechanism for accurate mating, along with colorful housing for easy identification. Its high current capacity and RoHS compliance make it ideal for various electronic applications needing dependable and easy-to-manage connectors.
JST PSIP03VRC Connector Socket Specifications:
- Current rating: 12 A AC, DC
- Voltage rating: 300 V AC, DC
- Temperature range: -25°C to +85°C
- Contact resistance: Initial value/ 10 mΩ max, After environmental tests/ 20 mΩ max
- Insulation resistance: 1,000 MΩ min
- Withstanding voltage: 1,500 VAC/minute
- Applicable wire: AWG #26 to #16
- Material: Copper alloy, tin-plated
- Housing material: Glass-filled PBT, UL94V-0
- RoHS compliant
Buy the JST Series PSI Connector Socket: PSIP03VRC
Get your JST Series PSI Connector Socket PSIP03VRC now for high-performance, secure connections in electronic assemblies. Designed with a 4.0mm pitch, it supports 3 circuits suitable for wire gauges from 26 to 16 AWG. Featuring a C keying system for correct mating, bold red housing for easy identification, and a secure lock mechanism, this connector guarantees stability and safety. It complies with RoHS regulations, handles up to 12 A current, and operates over -25°C to +85°C, making it perfect for your reliable wiring needs.
Order your JST Series PSI connector socket PSIP03VRC today and ensure secure, reliable wiring for your electronic projects with easy identification and robust locking features.
Frequently Asked Questions
Where can I buy JST PSIP03VRC?
You can click on the BUY or RFQ button to purchase PSIP03VRC from an authorized JST distributor.
How do I troubleshoot issues or seek technical support for part PSIP03VRC?
You can download the PSIP03VRC datasheet or visit the JST website for support.
Who is the manufacturer of PSIP03VRC?
JST
