JST RF06 RF Connector Receptacle
This 6-position RF series connector receptacle with a 2.54mm pitch features a female socket design, ideal for RF signal connections. It is a crimp type connector with a black finish, suitable for free hanging mounting. Constructed with reliable phosphor bronze contacts and PBT housing, it can handle currents up to 2A and voltages up to 250V. Its design ensures easy insertion and secure connection, making it ideal for high-density RF applications in various electronic devices and communication equipment.
JST RF06 RF Connector Receptacle Specifications:
- Current rating: 2A AC, DC (AWG #24)
- Voltage rating: 250V AC, DC
- Temperature range: -55°C to +105°C (gold-plated), -55°C to +85°C (tin-plated)
- Contact resistance: Initial value/15mΩ max, after environmental testing/30mΩ max
- Insulation resistance: 1,000MΩ min
- Withstanding voltage: 1,500V AC/minute
- Applicable wire: AWG #30 to #24
- Applicable PC board thickness: 1.2 to 1.6mm
- Material: Phosphor bronze contacts, PBT housing, black color
- Finish: Nickel-undeoxed, gold-plated or tin-plated options
- Standards: Recognized by UL60389, Certified LR20812
Buy the Buy JST RF Connector Part Number RF06 Online
Order the JST RF06 RF connector receptacle online today and enjoy a high-quality, space-efficient, and reliable solution for RF signal connections. Designed for easy crimping, the black finish offers durability and corrosion resistance. Its 2.54mm pitch and 6-position layout make it ideal for high-density circuit designs in electronic devices, communication equipment, and automation systems. Trust JST's proven quality for long-lasting performance, with features like high current capacity, wide temperature range, and UL recognition to ensure your projects meet the highest standards of reliability and safety.
Get JST RF06 today—built for reliable RF signal connections with high-density, space-saving design and easy crimping for complex electronic assemblies.
Frequently Asked Questions
Where can I buy JST RF06?
You can click on the BUY or RFQ button to purchase RF06 from an authorized JST distributor.
How do I troubleshoot issues or seek technical support for part RF06?
You can download the RF06 datasheet or visit the JST website for support.
Who is the manufacturer of RF06?
JST
