JST S02BCZHKB1LFSN Connector Header
This CZ Series connector header with a 2-position configuration is designed for wire gauges 28-26 AWG, featuring a 1.5mm pitch for compact, high-density connections. Suitable for applications up to 100V AC/DC, it offers a distortion-resistant construction, low profile, and reliable insulation displacement. Made from flame-retardant PBT UL94V-0 material, the header has tin-plated copper contacts, ensuring excellent conductivity and corrosion resistance. Ideal for harnessing, board-to-wire, and wire-to-wire connections in automation, industrial, and control systems, it features easy assembly, RoHS compliance, and wide panel thickness compatibility.
JST S02BCZHKB1LFSN Connector Header Specifications:
- Number of Poles: 2
- Pitch: 1.5mm
- Wire Gauge: 28-26 AWG
- Voltage Rating: 100V AC/DC
- Current Rating: 2A
- Material: Contact - Copper alloy, Tin-plated; Housing - PBT UL94V-0
- Color: Natural
- Temperature Range: -25°C to +85°C
- RoHS compliance: Yes
- Model No.: S02BCZHKB1LFSN
- Size: Suitable for 28-26 AWG wires, compact structure
Buy the JST S02BCZHKB1LFSN – Reliable Connectors for Industrial Applications
Secure your automation wiring with the JST Connector Header, offering a 2-position configuration, 1.5mm pitch, and compatibility with 28-26 AWG wires. Designed for reliability and ease of assembly, it withstands up to 100V and features durable tin-plated copper contacts. Made from flame-retardant PBT UL94V-0 material, this connector ensures long-term performance in industrial environments. Ideal for harnessing, board-to-wire, and wire-to-wire connections, it complies with RoHS standards and supports wide panel thicknesses, ensuring versatility and safety in your applications.
Buy JST S02BCZHKB1LFSN now and experience unmatched reliability and performance in industrial wiring and connector solutions.
Frequently Asked Questions
Where can I buy JST S02BCZHKB1LFSN?
You can click on the BUY or RFQ button to purchase S02BCZHKB1LFSN from an authorized JST distributor.
How do I troubleshoot issues or seek technical support for part S02BCZHKB1LFSN?
You can download the S02BCZHKB1LFSN datasheet or visit the JST website for support.
Who is the manufacturer of S02BCZHKB1LFSN?
JST
