JST 09DB4KLF connector header
This 9-position connector header from the DB series features a 2.5mm pitch suitable for 24-28 AWG wires. It offers reliable insulation displacement connection with a low profile height of 7.1mm and a width of 4.1mm. The connector includes twin U-slot insulation displacement sections, a locking solder tail for stable connections, and strain relief to prevent stress on wires due to vibration or bending. Compatible with standard SBN and SCN connectors, it is ideal for secure, compact wire-to-board applications in electronic assemblies.
JST 09DB4KLF connector header Specifications:
- Current rating: 2A AC, DC (AWG #24)
- Voltage rating: 250V AC, DC
- Temperature range: -25°C to +85°C
- Insulation resistance: 1,000M min.
- Withstanding voltage: 1,500V AC/minute
- Applicable wire: UL1007; AWG #28, #26, #24, 7 strands, tin-coated
- Insulation Outer Diameter: 1.0 to 1.5mm
- Applicable PC board thickness: 1.6mm
- Material: Phosphor bronze contact, nickel-undercoated, tin-plated; Housing: PAS, UL94V-0
- RoHS compliant
- Connector dimensions vary by circuit number, with lock features ensuring stable connection
Buy the Buy JST DB Series 09DB4KLF Part Number 09DB4KLF Online
Purchase the JST DB Series 09DB4KLF connector online today and enjoy a reliable, compact solution for wire-to-board connections. Featuring a 2.5mm pitch and suitable for 24-28 AWG wires, this low profile connector provides excellent insulation displacement connectivity, lock stability, and strain relief. Its robust design makes it ideal for electronic assemblies requiring secure connections in limited spaces. Certified RoHS compliant, it offers dependable performance in various industrial and consumer electronic applications. Buy now to ensure your projects are equipped with high-quality, durable components for long-term use.
Order your JST DB Series 09DB4KLF connector today and ensure secure, reliable wire-to-board connections with durable insulation displacement design.
Frequently Asked Questions
Where can I buy JST 09DB4KLF?
You can click on the BUY or RFQ button to purchase 09DB4KLF from an authorized JST distributor.
How do I troubleshoot issues or seek technical support for part 09DB4KLF?
You can download the 09DB4KLF datasheet or visit the JST website for support.
Who is the manufacturer of 09DB4KLF?
JST
