JST SHLDP30VS1B Shielded Connector
This is a 30-circuit shielded connector featuring a secure lock type housing, designed for reliable electrical connections with enhanced security. It is made of PBT material with a UL94V-0 rating, natural white color, and includes a secure locking mechanism to prevent deformation of contacts and ensure stable connections under external forces. Suitable for small electronic equipment and LCD applications, it supports applications requiring up to 50V AC/DC and 1.0A current. The connector is RoHS compliant, with a compact design and precise dimensions for easy integration.
JST SHLDP30VS1B Shielded Connector Specifications:
- Current rating: 1.0A AC, DC (AWG #28)
- Voltage rating: 50V AC, DC
- Temperature range: -25°C to +85°C
- Contact resistance: Initial value/30mΩ max., after environmental testing/40mΩ max.
- Insulation resistance: 100MΩ minimum
- Withstanding voltage: 500V AC for 1 minute
- Material: PBT, UL94V-0, natural (white)
- RoHS compliance: Yes
- Dimensions: Length varies with model, for example, 130mm length for 30 circuits, proper for small electronic modules
- Number of circuits: 30
- Housing: Secure lock type, designed to prevent deformation of contacts
- Contact Material: Phosphor bronze, gold-plated for reliable contact
- Solder tab: Brass, tin-plated
- Applicable wire size: 0.032~0.08mm (AWG #28-#30)
- Reel quantity: 2,000 units per reel
Buy the Buy JST Shielded Connector Part Number SHLDP30VS1B Online
Purchase the JST shielded connector SHLDP30VS1B online to ensure your small electronic equipment and LCD project benefit from a secure, high-quality connection. This 30-circuit connector features a lock housing for stability and is made of flame-retardant PBT material. It supports up to 50V and 1.0A current, ideal for reliable performance in various electronic assemblies. Buy now for fast delivery and enhance your product’s durability with trusted JST quality.
Buy JST SHLDP30VS1B now and experience reliable and secure electrical connections for small electronic applications.
Frequently Asked Questions
Where can I buy JST SHLDP30VS1B?
You can click on the BUY or RFQ button to purchase SHLDP30VS1B from an authorized JST distributor.
How do I troubleshoot issues or seek technical support for part SHLDP30VS1B?
You can download the SHLDP30VS1B datasheet or visit the JST website for support.
Who is the manufacturer of SHLDP30VS1B?
JST
