JST SM08BSSRHTBLFSN Surface-mount connector header
This gray surface-mount right-angle connector header from the SSR series features 8 positions with a 1.00mm pitch, rated for up to 50V. Designed for compact electronic applications, it utilizes twin U-slot insulation displacement sections and 3-point grip construction for secure connections. Compatible with conductor sizes up to AWG #32, it is constructed with phosphor bronze contacts, tin-plated for enhanced durability, and housed in gray ULS4V-0 rated plastic. Its precise dimensions and RoHS compliance make it ideal for space-constrained, reliable electronic assemblies, especially in robotic and automation systems.
JST SM08BSSRHTBLFSN Surface-mount connector header Specifications:
- Number of positions: 8
- Pitch: 1.00mm
- Rated voltage: 50V AC/DC
- Current rating: 0.5A
- Temperature range: -25°C to +85°C
- Contact material: Phosphor bronze, tin-plated
- Housing: PA 46, ULS4V-0, gray
- Wire compatibility: Conductor size AWG #32, 7 strands, tin-coated, annealed copper
- Dimensions: Length approximately 7.0 mm, width 10.6 mm, height 16.6 mm
- RoHS compliant and recognized by standards
Buy the JST Series SSR Connector: SM08BSSRHTBLFSN
Order the JST SSR series surface-mount connector header SM08BSSRHTBLFSN online today. Perfect for compact electronic designs, it offers reliable electrical connections with a 1.00mm pitch and 50V rating. Its twin U-slot insulation displacement sections and 3-point grip ensure secure and stable contact, suitable for robotic and automation projects. Made from durable materials, RoHS-compliant, and designed for easy mounting in space-constrained environments, this connector guarantees performance and longevity in your electronic assemblies.
Get JST SSR connector header SM08BSSRHTBLFSN today—built for precision, secure connections, and long-lasting durability.
Frequently Asked Questions
Where can I buy JST SM08BSSRHTBLFSN?
You can click on the BUY or RFQ button to purchase SM08BSSRHTBLFSN from an authorized JST distributor.
How do I troubleshoot issues or seek technical support for part SM08BSSRHTBLFSN?
You can download the SM08BSSRHTBLFSN datasheet or visit the JST website for support.
Who is the manufacturer of SM08BSSRHTBLFSN?
JST
