JST XARP03VWGT4 Crimp Connector
The XA series crimp plug housing connector features a compact 2.5 mm pitch and 2-position configuration, designed for reliable electrical connections in industrial and electronic applications. Made from high-quality materials, it supports a current rating of 3A AC/DC at 250V and is compatible with AWG #28 to #20 wires. The connector complies with RoHS standards and features a secure locking mechanism, solder crack prevention, and glow wire test compatibility, making it suitable for various demanding environments. Its robust design ensures dependable performance and easy installation across multiple uses.
JST XARP03VWGT4 Crimp Connector Specifications:
- Current rating: 3A AC/DC at 250V
- Voltage rating: 250V AC/DC
- Temperature range: -25°C to +105°C
- Contact resistance: Initial value/ 10mΩ @ max, after environmental testing/ 20mΩ max
- Insulation resistance: 1,000MΩ min
- Withstanding voltage: 1,000V AC/minute
- Applicable wire: AWG #28 to #20
- Applicable PCB thickness: 1.6 mm
- Material: Phosphor bronze, tin-plated
- RoHS compliant
- Glow wire test compatible
- Physical dimensions: 7.3 x 10.5 mm
- Connector type: Through-hole, top entry
- Crimp style, disconnectable
Buy the JST Series XA: 2.5mm Pitch Crimp Connector XARP03VWGT4
Purchase the JST Series XA crimp connector XARP03VWGT4 online today for dependable, high-quality electrical connections. This compact 2-position, 2.5 mm pitch connector is ideal for industrial and electronic applications, ensuring secure and reliable performance. Made from high-grade materials, it supports up to 3A at 250V and is RoHS compliant, with glow wire test compatibility for safety in demanding environments. Simple to install, it offers consistent quality, guaranteed durability, and excellent performance to meet your project needs efficiently.
Order your JST Series XA XARP03VWGT4 crimp connector today and ensure reliable electrical connections with durable, RoHS-compliant performance.
Frequently Asked Questions
Where can I buy JST XARP03VWGT4?
You can click on the BUY or RFQ button to purchase XARP03VWGT4 from an authorized JST distributor.
How do I troubleshoot issues or seek technical support for part XARP03VWGT4?
You can download the XARP03VWGT4 datasheet or visit the JST website for support.
Who is the manufacturer of XARP03VWGT4?
JST
