KEMET A767MU686M1JLAE030 Polymer Aluminum Capacitor
The KEMET A767MU686M1JLAE030 is a polymer aluminum capacitor specifically engineered for surface mount technology (SMT) applications. Featuring a capacitance of 68µF and a voltage rating of 63VDC (with a surge voltage of 72VDC), this capacitor is ideal for applications requiring high capacitance density and excellent performance. Its polymer aluminum construction provides low ESR and high ripple current handling capabilities, making it suitable for power supplies, DC-DC converters, and other demanding electronic circuits. The capacitor's operating temperature range of -55°C to +105°C ensures reliable performance across a wide range of environmental conditions. It is RoHS compliant and packaged in tape and reel format for automated assembly processes.
KEMET A767MU686M1JLAE030 Polymer Aluminum Capacitor Specifications:
- Series: A767
- Dielectric: Polymer Aluminum
- Style: SMD Can
- Description: Surface Mount, Polymer Aluminum
- RoHS: Yes
- Lead: V-Chip
- AEC-Q200: No
- Halogen Free: Yes
- Capacitance: 68 uF
- Capacitance Tolerance: 20%
- Voltage DC: 63 VDC, 72 VDC (Surge)
- Temperature Range: -55/+105°C
- Rated Temperature: 105°C
- Life: 2000 Hrs
- Resistance: 30 mOhms (100kHz 20C)
- ESR/Impedance at 100kHz: 30 mOhms
- Ripple Current: 2450 mAmps (100kHz 105C)
- Leakage Current: 856 uA (2min 20°C)
- High Temperature Solder: No
- Packaging: T&R, 380mm
- Packaging Quantity: 400
- Dimensions D: 10mm +/-0.5mm
- Dimensions L: 12.6mm +/-0.3mm
- Dimensions W: 0.8 - 1.1mm
- Dimensions F: 0.2mm MAX
- Dimensions A: 10.3mm +/-0.2mm
- Dimensions B: 10.3mm +/-0.2mm
- Dimensions C: 11mm +/-0.2mm
- Dimensions G: 0.35mm +/-0.2mm
- Dimensions P: 4.6mm +/-0.2mm
Buy the A767MU686M1JLAE030 KEMET Polymer Aluminum Capacitor | myMectronic
Purchase the KEMET A767MU686M1JLAE030 Polymer Aluminum Capacitor securely and efficiently through our online store.
Buy Now
Frequently Asked Questions
Where can I buy KEMET A767MU686M1JLAE030?
You can click on the BUY or RFQ button to purchase A767MU686M1JLAE030 from an authorized KEMET distributor.
How do I troubleshoot issues or seek technical support for part A767MU686M1JLAE030?
You can download the A767MU686M1JLAE030 datasheet or visit the KEMET website for support.
Who is the manufacturer of A767MU686M1JLAE030?
KEMET
