KEMET A768KS397M1ELAE019 Polymer Aluminum Capacitor
The KEMET A768KS397M1ELAE019 is a polymer aluminum capacitor specifically engineered for surface mount technology. Featuring a capacitance of 390µF and a voltage rating of 25VDC, this capacitor is ideal for applications requiring high capacitance density and excellent performance. Its robust design and wide operating temperature range (-55°C to +125°C) make it suitable for demanding industrial and consumer electronics applications. The capacitor's low ESR and long life contribute to enhanced circuit reliability and performance. It is RoHS compliant, aligning with environmental regulations and promoting sustainable practices.
KEMET A768KS397M1ELAE019 Polymer Aluminum Capacitor Specifications:
- Series: A768
- Dielectric: Polymer Aluminum
- Style: SMD Can
- Description: Surface Mount, Polymer Aluminum
- RoHS: Yes
- Lead: V-Chip
- AEC-Q200: No
- Halogen Free: Yes
- Capacitance: 390 uF
- Capacitance Tolerance: 20%
- Voltage DC: 25 VDC, 28.7 VDC (Surge)
- Temperature Range: -55/+125°C
- Rated Temperature: 125°C
- Life: 2000 Hrs
- Resistance: 19 mOhms (100kHz 20C)
- Ripple Current: 2325 mAmps (100kHz 125C)
- Leakage Current: 1950 uA (2min 20°C)
- High Temperature Solder: No
- Packaging: T&R, 380mm
- Packaging Quantity: 400
- D: 8mm +/-0.5mm
- L: 12.2mm +/-0.3mm
- W: 0.8 - 1.1mm
- F: 0.2mm MAX
- A: 8.3mm +/-0.2mm
- B: 8.3mm +/-0.2mm
- C: 9mm +/-0.2mm
- G: 0.35mm +/-0.2mm
- P: 3.2mm NOM
Buy the A768KS397M1ELAE019 KEMET Polymer Aluminum Capacitor | myMectronic
Purchase the KEMET A768KS397M1ELAE019 capacitor securely and efficiently through our online platform.
Buy Now
Frequently Asked Questions
Where can I buy KEMET A768KS397M1ELAE019?
You can click on the BUY or RFQ button to purchase A768KS397M1ELAE019 from an authorized KEMET distributor.
How do I troubleshoot issues or seek technical support for part A768KS397M1ELAE019?
You can download the A768KS397M1ELAE019 datasheet or visit the KEMET website for support.
Who is the manufacturer of A768KS397M1ELAE019?
KEMET
