KEMET ALC10A331EE550 Aluminum Electrolytic Capacitors
KEMET's ALC10 Series snap-in aluminum electrolytic capacitors are designed for high voltage up to 550 VDC and long life, making them ideal for industrial power applications. Featuring a rugged construction, they offer excellent surge voltage capability and high ripple current handling. Operating at +85°C, these capacitors are suitable for frequency converters, UPS systems, and switch mode power supplies, providing reliable performance up to 18,000 hours. Their compact size and durable casing ensure ease of installation in demanding environments.
KEMET ALC10A331EE550 Aluminum Electrolytic Capacitors Specifications:
- Capacitance Range: 56 - 82,000 uF
- Rated Voltage: 35-550 VDC
- Operating Temperature: -40 to +85°C
- Capacitance Tolerance: +20% at 100 Hz / +20°C
- Endurance: Up to 18,000 hours at +85°C
- Leakage Current: Specified limits, tested at +20°C
- Vibration Resistance: 0.75 mm displacement amplitude or 10 g max acceleration for D<40mm; 0.35 mm or 5 g for D>40mm
- Surge Voltage Capability: Up to 550 VDC with specific pulse durations
- Polarity: Polarized, +ve to anode, -ve to cathode, withstands short reverse voltage up to 2 V
- Mounting: Can be mounted upright or inclined, with single point termination for easy installation
- Safety Vent: Designed to relieve internal pressure during overpressure
Buy the KEMET Series ALC10 Voltage: 550 VDC Aluminum Electrolytic Capacitors
Shop KEMET aluminum electrolytic capacitors from the ALC10 series online today. Designed for high voltage up to 550 VDC, these capacitors provide long life, excellent surge voltage capability, and high ripple current handling. Perfect for industrial power supplies, UPS systems, frequency converters, and switch mode power supplies, they feature durable construction, compact size, and a rugged casing that ensures reliable operation even in demanding environments. Purchase now for high performance and long-term durability in your power electronic applications!
Get KEMET ALC10 550 VDC Aluminum Electrolytic Capacitors today—built for high reliability, long-lasting durability, and high ripple current in power electronics.
Frequently Asked Questions
Where can I buy KEMET ALC10A331EE550?
You can click on the BUY or RFQ button to purchase ALC10A331EE550 from an authorized KEMET distributor.
How do I troubleshoot issues or seek technical support for part ALC10A331EE550?
You can download the ALC10A331EE550 datasheet or visit the KEMET website for support.
Who is the manufacturer of ALC10A331EE550?
KEMET
