KEMET ALC70A471CF400 Aluminum Electrolytic Capacitor
The aluminum electrolytic capacitor is designed for high-voltage applications, featuring a 470 uF capacitance, 20% tolerance, and 400 VDC voltage rating. It operates effectively within a temperature range of -40°C to +85°C, ensuring reliability in demanding environments. The snap-in design facilitates easy installation, while the RoHS-compliant, halogen-free construction makes it suitable for environmentally conscious projects. With a shelf life of 156 weeks, this capacitor delivers stable performance, low ESR, and high ripple current capacity, making it ideal for power supplies, inverter circuits, and industrial equipment.
KEMET ALC70A471CF400 Aluminum Electrolytic Capacitor Specifications:
- Capacitance: 470 uF
- Capacitance Tolerance: 20%
- Voltage DC: 400 VDC, 440 VDC (Surge)
- Temperature Range: -40°C to +85°C
- Rated Temperature: 85°C
- Shelf Life: 156 Weeks
- Leakage Current: 1128 uA (5 min at 20°C)
- Ripple Current: 2.287 Amps (100Hz, 85°C), 5.732 Amps (10kHz, 85°C)
- ESR Resistance: 209-9 mOhms (100Hz, 20°C), 151.9 mOhms (10kHz, 20°C)
- Component Weight: 60g
- Dimensions: D 30mm, Length varies, including sleeving
- RoHS Compliant: Yes
- Halogen Free: Yes
- Lead Type: 2 Pin
- Life Expectancy: 13,000 hours at rated voltage and 85°C
Buy the Buy KEMET Aluminum Electrolytic Capacitor Part Number ALC70A471CF400 Online
Experience the dependable performance of the KEMET Aluminum Electrolytic Capacitor ALC70A471CF400, designed with a 470 uF capacitance and 400 VDC voltage to ensure quality in power supply and industrial circuits. Its robust construction supports operation from -40°C to +85°C, making it suitable for demanding environments. The snap-in design simplifies installation while its environmentally friendly, halogen-free materials meet RoHS standards. With an operational life of over 13,000 hours at rated conditions, purchase this high-voltage capacitor online for reliable, long-term service in your electronic applications.
Get KEMET ALC70A471CF400 today—built for high-voltage power applications with reliable performance and long-lasting durability.
Frequently Asked Questions
Where can I buy KEMET ALC70A471CF400?
You can click on the BUY or RFQ button to purchase ALC70A471CF400 from an authorized KEMET distributor.
How do I troubleshoot issues or seek technical support for part ALC70A471CF400?
You can download the ALC70A471CF400 datasheet or visit the KEMET website for support.
Who is the manufacturer of ALC70A471CF400?
KEMET
