KEMET R75GR433050H0J Automotive Film Capacitor
This automotive-grade film capacitor features metallized polypropylene dielectric, rated at 3.3 microfarads with a 5% tolerance, and rated for 160 VDC operation at a temperature of 105°C. It is designed for pulse applications, RoHS compliant, and includes wire leads with radial mounting style. The capacitor offers high insulation resistance of 9.09 GOhms, low dissipation factor of 0.06% at 1kHz, and a resistance of 7.23mOhms at 100kHz. Its compact dimensions and qualified automotive ratings make it suitable for demanding electronic circuits in automotive environments.
KEMET R75GR433050H0J Automotive Film Capacitor Specifications:
- Dielectric: Metallized Polypropylene
- Capacitance: 3.3 uF
- Tolerance: 5%
- Voltage DC: 160 VDC
- Voltage AC: 90 VAC
- Temperature Range: -55°C to +125°C
- Rated Temperature: 105°C
- Dimensions: Length 32mm +0.3/-0.7mm, Height 22mm +0.1/-0.7mm, Diameter 18mm +0.2/0.7mm, Lead Spacing 27.5mm +/-0.4mm
- Insulation Resistance: 9.09 GOhms
- Dissipation Factor: 0.06% at 1kHz
- Resistance: 7.23mOhms at 100kHz
- Ripple Current: 90 mA
- Inductance: 18 nH
- Operating Temperature: -55°C to +125°C
- Features: RoHS compliant, Automotive Grade, Pulse resistant
- Compliance: AEC-Q200 qualified
Buy the Buy KEMET Automotive Grade Film Capacitor Part Number R75GR433050H0J Online
Discover the KEMET automotive-grade film capacitor with 3.3 microfarads, rated at 160 volts DC and operating up to 105°C. Designed with metallized polypropylene dielectric, it is ideal for pulse applications and demanding automotive electronics. This high-reliability capacitor features RoHS compliance, wire leads for radial mounting, and excellent insulation resistance. Its compact size and exceptional electrical characteristics ensure reliable circuit performance. Perfect for engineers seeking durable, high-performance components for automotive, power supplies, and industrial applications. Purchase online today for immediate delivery.
Get KEMET R75GR433050H0J today—built for automotive durability, pulse resistance, and long-lasting performance in demanding electronic circuits.
Frequently Asked Questions
Where can I buy KEMET R75GR433050H0J?
You can click on the BUY or RFQ button to purchase R75GR433050H0J from an authorized KEMET distributor.
How do I troubleshoot issues or seek technical support for part R75GR433050H0J?
You can download the R75GR433050H0J datasheet or visit the KEMET website for support.
Who is the manufacturer of R75GR433050H0J?
KEMET
