KEMET ALF20C102EL450 Aluminum Electrolytic Capacitor
The KEMET ALF20 press-fit aluminum electrolytic capacitors eliminate soldering, ensuring reliable electrical contact with vibration resistance. Designed for high voltage up to 450 VDC and surge capabilities, these capacitors support high ripple currents and have a long lifespan of up to 18,000 hours at +85°C. Compact and easy to replace in various applications, they are ideal for dependable performance in demanding environments. Suitable for electronic systems needing high-voltage filtering, power supply smoothing, and vibration-resistant connections, these capacitors deliver durability and ease of installation in technical and industrial settings.
KEMET ALF20C102EL450 Aluminum Electrolytic Capacitor Specifications:
- Capacitance: 1,000 uF
- Capacitance Tolerance: 20%
- Voltage DC: 450 VDC, 495 VDC (Surge)
- Temperature Range: -40/+85°C
- Rated Temperature: 85°C
- Dimensions: D 40mm +1mm, L 80mm +/-2mm, 22.5mm +/-0.1mm, LL 5.5mm +/-1mm, F 1.486mm +/-0.076mm
- Leakage Current: 2700 uA (5min 20°C)
- Resistance: 14mOhms (L00Hz 20°C), 75mOhms (10kHz 20°C)
- Ripple Current: Supports high ripple currents at 85°C
- Packaging: Bulk, Quantity: 36
- RoHS Compliant: Yes
- Style: Press-Fit, Aluminum Electrolytic
- Lead: 4 Pin Press-Fit
- Shelf Life: 156 Weeks
- Component Weight: 131g
- Certification: Not AEC-Q200
Buy the KEMET Series ALF20 Aluminum Electrolytic Capacitor: ALF20C102EL450
Order the KEMET ALF20C102EL450 aluminum electrolytic capacitor online to ensure reliable high-voltage filtering and vibration resistance. Designed for dependable performance in power electronics and industrial equipment, this press-fit capacitor provides a long lifespan of up to 18,000 hours at +85°C and handles surge voltages up to 495 VDC. Its compact design simplifies installation and maintenance, making it ideal for demanding applications requiring high ripple currents, durability, and easy field replacement. Purchase today for quality assurance and immediate availability.
Get KEMET ALF20C102EL450 today—built for high voltage and vibration-resistant performance in industrial and power supply systems.
Frequently Asked Questions
Where can I buy KEMET ALF20C102EL450?
You can click on the BUY or RFQ button to purchase ALF20C102EL450 from an authorized KEMET distributor.
How do I troubleshoot issues or seek technical support for part ALF20C102EL450?
You can download the ALF20C102EL450 datasheet or visit the KEMET website for support.
Who is the manufacturer of ALF20C102EL450?
KEMET
