KEMET ALF70C432DD100 Aluminum Electrolytic Capacitor
The ALF70C432DD100 is a high-quality aluminum electrolytic capacitor designed for reliable power filtering and energy storage in electronic circuits. With a capacitance of 4300 uF and a voltage rating of 100 VDC, it operates effectively within a temperature range of -40°C to +85°C. Featuring a press-fit style with four pins, RoHS compliance, and halogen-free construction, this component ensures durability and environmental standards. Its compact dimensions and long shelf life of 156 weeks make it ideal for demanding industrial and electronic applications, providing stable performance under high ripple currents and surge conditions.
KEMET ALF70C432DD100 Aluminum Electrolytic Capacitor Specifications:
- Capacitance: 4300 uF
- Capacitance Tolerance: 20%
- Voltage DC: 100 VDC, 115 VDC (Surge)
- Temperature Range: -40°C to +85°C
- Rated Temperature: 85°C
- Dimensions: Diameter 36mm +1mm, Length 40mm +1-2mm
- Style: Press-Fit, Aluminum Electrolytic
- Lead Type: 4 Pin Press-Fit
- RoHS Compliant: Yes
- Halogen Free: Yes
- Shelf Life: 156 Weeks
- Ripple Current at 85°C: 5.635 A (100Hz), 7.303 A (10kHz)
- Leakage Current: 2580 uA (5 min at 20°C)
- Resistance: 0.025 mOhms (100Hz 20°C), 53.39 mOhms (LOKHz 20°C)
Buy the KEMET Series ALF70 Aluminum Electrolytic Capacitor: ALF70C432DD100
Experience reliable power filtering with the KEMET ALF70C432DD100 Aluminum Electrolytic Capacitor, featuring 4300 uF capacitance and 100 VDC voltage. This press-fit component is RoHS compliant, halogen-free, and designed to operate within -40°C to +85°C. Its compact size and long shelf life of 156 weeks ensure durability and performance for demanding industrial circuits. Perfect for power supplies, energy storage, and ripple filtering, this capacitor delivers stability under high surge and ripple currents, making it a trusted choice for sophisticated electronic systems.
Get KEMET ALF70C432DD100 today—built for precision and long-lasting durability in power supply applications.
