KEMET ALF70C562DF100 Aluminum Electrolytic Capacitor
The aluminum electrolytic capacitor from the ALF70 series offers a capacitance of 5,600 uF with a 20% tolerance, rated for 100 VDC operation and ranging from -40°C to +85°C. Its press-fit style with four pins ensures secure mounting on PCB, making it suitable for applications requiring high capacitance and voltage stability. The device features low equivalent series resistance (ESR), leakage current of 3360 uA, and operates reliably at 85°C for extended life up to 24,000 hours under rated conditions. The capacitor's compact dimensions include a diameter of 35mm +1mm and a height of 50mm ±2mm, with a weight of approximately 80g.
KEMET ALF70C562DF100 Aluminum Electrolytic Capacitor Specifications:
- Capacitance: 5600 uF
- Capacitance Tolerance: 20%
- Voltage DC: 100 VDC
- Surge Voltage: 115 VDC
- Temperature Range: -40°C to +85°C
- Rated Temperature: 85°C
- Dimensions: Diameter 35mm +1mm, Height 50mm ±2mm
- Lead Type: 4 Pin Press-Fit
- Leakage Current: 3360 uA (5 min at 20°C)
- Ripple Current: 8.764 A at 85°C
- Equivalent Series Resistance: 41.06 mOhms (10kHz at 20°C), 00-98 mOhms (100Hz at 20°C)
- Shelf Life: 156 weeks
- Operating Life: 15,000 hours at rated voltage and temperature, 24,000 hours at 85°C
- RoHS Compliant: Yes
- Weight: Approximately 80g
Buy the KEMET Series ALF70 Aluminum Electrolytic Capacitor: ALF70C562DF100
Enhance your electronic designs with the KEMET ALF70 series aluminum electrolytic capacitor. Featuring a 5600 microfarad capacitance, 100 VDC rating, and operating temperature from -40°C to +85°C, this press-fit component ensures secure PCB mounting and long-life performance. Its low ESR, leakage current of 3360 uA, and extended lifespan up to 24,000 hours at rated conditions make it ideal for power supplies, filtering, and energy storage applications. Reliable and compliant with RoHS standards, it's your perfect choice for demanding electronics.
Buy KEMET ALF70C562DF100 now and experience unmatched reliability and high-performance stability for your electronic projects.
Frequently Asked Questions
Where can I buy KEMET ALF70C562DF100?
You can click on the BUY or RFQ button to purchase ALF70C562DF100 from an authorized KEMET distributor.
How do I troubleshoot issues or seek technical support for part ALF70C562DF100?
You can download the ALF70C562DF100 datasheet or visit the KEMET website for support.
Who is the manufacturer of ALF70C562DF100?
KEMET
