KEMET ALF70G272FP400 Electrolytic Capacitor
The aluminum electrolytic capacitor is a press-fit style component with a capacitance of 2,700 uF and a voltage rating of 400 VDC, suitable for high-voltage and temperature applications. It features a RoHS-compliant, halogen-free design with a shelf life of 156 weeks, operating temperature range from -40°C to +85°C, and a rated temperature of 85°C. The capacitor has low Equivalent Series Resistance (ESR), with resistance measurements of 0.478 mΩ at 100Hz and 30.08 mΩ at 10kHz, ensuring high ripple current capability at elevated temperatures.
KEMET ALF70G272FP400 Electrolytic Capacitor Specifications:
- Capacitance: 2,700 uF
- Capacitance Tolerance: 20%
- Voltage DC: 400 VDC, 440 VDC (Surge)
- Temperature Range: -40°C to +85°C
- Rated Temperature: 85°C
- Dimensions: Diameter 45mm ±1mm, Length 105mm ±2mm
- Shelf Life: 156 Weeks
- Ripple Current at 85°C: 7.487 Amps at 100Hz, 15.09 Amps at 10kHz
- Leakage Current: 6000 uA (5 min at 20°C)
- Resistance: 0.478 mΩ (100Hz 20°C), 30.08 mΩ (10kHz 20°C)
- Leakage Current: 6000 uA
- RoHS Compliant: Yes
- Halogen Free: Yes
- Style: Press-Fit
- Lead: 5 Pin Press-Fit
- Packaging: Bulk
- Shelf Life: 156 Weeks
Buy the Buy YAGEO Aluminum Electrolytic Capacitor Part Number ALF70G272FP400 Online
Purchase the high-quality YAGEO electrolytic capacitor ALF70G272FP400 online today. Engineered for demanding applications, this 2,700 uF, 400 VDC capacitor features a robust press-fit design, excellent temperature range from -40°C to +85°C, and a long shelf life of 156 weeks. Its low ESR ensures high ripple current capacity and reliable operation in power supplies and industrial equipment. Make your purchase now to ensure your project benefits from proven durability and performance in critical electronic systems.
Buy YAGEO ALF70G272FP400 aluminum electrolytic capacitor now and experience reliable high-voltage performance for your demanding electronic applications.
Frequently Asked Questions
Where can I buy KEMET ALF70G272FP400?
You can click on the BUY or RFQ button to purchase ALF70G272FP400 from an authorized KEMET distributor.
How do I troubleshoot issues or seek technical support for part ALF70G272FP400?
You can download the ALF70G272FP400 datasheet or visit the KEMET website for support.
Who is the manufacturer of ALF70G272FP400?
KEMET
