KEMET ALF80C561EF450 Aluminum Electrolytic Capacitor
The ALF80 series by KEMET features aluminum electrolytic capacitors with a capacitance of 560 uF, a voltage rating of 450 VDC, and a temperature range of -40°C to +105°C. Designed with a press-fit style, these components are RoHS compliant and weigh approximately 105 grams. Suitable for high-reliability applications, they offer a ripple current of up to 3.2 Amps at 105°C. The capacitors include 4-pin press-fit leads, have a shelf life of 156 weeks, and are ideal for PCB mounting and power supply filtering.
KEMET ALF80C561EF450 Aluminum Electrolytic Capacitor Specifications:
- Capacitance: 560 uF
- Tolerance: 20%
- Voltage DC: 450 VDC, 495 VDC (Surge)
- Temperature Range: -40°C to +105°C
- Rated Temperature: 105°C
- Dimensions: Diameter 40mm ±1mm, Length 45mm ±1mm
- Leakage Current: 756 uA (5min at 20°C)
- Ripple Current: 3.2 Amps (100Hz at 105°C), 7.969 Amps (10kHz at 105°C)
- Equivalent Series Resistance: 240 mOhms (100Hz, 20°C), 139.7 mOhms (10kHz, 20°C)
- Shelf Life: 156 Weeks
- Weight: 105 grams
- Lead Type: 4 Pin Press-Fit
- RoHS Compliant
- Packaging: Bulk
Buy the KEMET ALF80C561EF450 – Reliable Aluminum Electrolytic Capacitor for Industrial Applications
Order the KEMET aluminum electrolytic capacitor with 560 microfarads capacitance and 450VDC rating today. Its robust press-fit design ensures secure PCB mounting and high reliability. Suitable for power supplies, filtering, and industrial electronics, this capacitor features a temperature range from -40°C to +105°C, a shelf life of 156 weeks, and low ESR. With a weight of 105 grams and compliant with RoHS standards, it offers optimal performance and durability for demanding electronic applications. Buy online now and ensure your project’s reliability.
Get KEMET ALF80C561EF450 today—built for precision and long-lasting durability in demanding power supply and filtering applications.
Frequently Asked Questions
Where can I buy KEMET ALF80C561EF450?
You can click on the BUY or RFQ button to purchase ALF80C561EF450 from an authorized KEMET distributor.
How do I troubleshoot issues or seek technical support for part ALF80C561EF450?
You can download the ALF80C561EF450 datasheet or visit the KEMET website for support.
Who is the manufacturer of ALF80C561EF450?
KEMET
