KEMET ALS30A153KE063 Aluminum Electrolytic Capacitor
The ALS30A153KE063 is an aluminum electrolytic capacitor designed for high-capacity energy storage and filtering in industrial electronics. With a capacitance of 15,000 uF and a voltage rating of 63 VDC, it supports long life and reliable operation across temperature ranges from -40°C to +85°C. Its screw terminal and aluminum construction ensure robustness and ease of mounting. This capacitor's low equivalent series resistance (ESR) and high ripple current capacity make it ideal for power supply filtering and energy storage applications. Its RoHS compliance guarantees environmental safety.
KEMET ALS30A153KE063 Aluminum Electrolytic Capacitor Specifications:
- Capacitance: 15,000 uF
- Voltage Rating: 63 VDC
- Temperature Range: -40°C to +85°C
- Dimensions: Diameter 75 mm, Length 82 mm
- Screw Terminal Mounting: M12x16
- Leakage Current: 5670 uA (5 min at 20°C)
- Ripple Current: 13.9 Amps (100Hz @ 5°C), 14.4 Amps (10kHz @ 85°C)
- Equivalent Series Resistance: 12 mOhms (100Hz 20°C), 11 mOhms (10kHz 20°C)
- Shelf Life: 156 weeks
- RoHS Compliant
- Weight: 220g
Buy the KEMET ALS30A153KE063 – Reliable Aluminum Electrolytic Capacitor for Industrial Applications
Purchase the KEMET ALS30A153KE063 aluminum electrolytic capacitor online today for your industrial and electronics projects. Featuring 15,000 uF capacitance at 63 VDC, it provides reliable energy storage, filtering, and long life performance across a wide temperature range from -40°C to +85°C. Its screw terminal design allows easy mounting and maintenance. The low ESR and high ripple current make it ideal for high-performance power supply systems, backup power, and energy storage applications, ensuring durability and efficiency in demanding environments.
Order your KEMET ALS30A153KE063 aluminum electrolytic capacitor today and enhance your power supply and energy storage systems with dependable quality.
Frequently Asked Questions
Where can I buy KEMET ALS30A153KE063?
You can click on the BUY or RFQ button to purchase ALS30A153KE063 from an authorized KEMET distributor.
How do I troubleshoot issues or seek technical support for part ALS30A153KE063?
You can download the ALS30A153KE063 datasheet or visit the KEMET website for support.
Who is the manufacturer of ALS30A153KE063?
KEMET
