KEMET ALS30A471DE350 Aluminum Electrolytic Capacitor
The ALS30 series aluminum electrolytic capacitor is designed for high voltage applications, offering a capacitance of 470 uF with a tolerance of 20%. It features a 350 VDC rating, operating effectively within a temperature range of -40°C to +85°C. Its robust construction includes screw terminals, making it suitable for industrial and power electronic applications. With a rated life of 11,000 hours at 85°C under ripple current conditions, it provides reliable performance and longevity in demanding environments. The capacitor's dimensions include a diameter of approximately 36mm and a length of 82mm, with a weight of 115g.
KEMET ALS30A471DE350 Aluminum Electrolytic Capacitor Specifications:
- Capacitance: 470 uF
- Capacitance Tolerance: 20%
- Voltage DC: 350 VDC, 385 VDC (Surge)
- Temperature Range: -40°C to +85°C
- Rated Temperature: 85°C
- Dimensions: Diameter 36mm +/-Lmm, Length 82mm +/-2mm
- Material: Aluminum Electrolytic
- Leakage Current: 987 uA (5 min, 20°C)
- Ripple Current: 34 Amps (100Hz, 85°C), 7.2 A (10kHz, 85°C)
- Shelf Life: 156 Weeks
- RoHS Compliant: Yes
- Mounting: Screw Terminal, Aluminum
- Component Weight: 115g
Buy the KEMET Series ALS30 Aluminum Electrolytic Capacitor: ALS30A471DE350
Secure your project with the KEMET ALS30A471DE350 aluminum electrolytic capacitor. Designed for high voltage applications, it offers 470 uF at 350 VDC and operates efficiently from -40°C to +85°C. Its screw terminal construction ensures secure mounting in industrial environments. With a rated life of over 11,000 hours at 85°C, this component guarantees durability and consistent performance. Its compact dimensions and RoHS compliance make it ideal for power electronics, industrial systems, and demanding electronic applications that require reliable, long-lasting capacitors.
Buy KEMET ALS30A471DE350 now and experience unmatched reliability and high-voltage performance for your power supply and industrial projects.
Frequently Asked Questions
Where can I buy KEMET ALS30A471DE350?
You can click on the BUY or RFQ button to purchase ALS30A471DE350 from an authorized KEMET distributor.
How do I troubleshoot issues or seek technical support for part ALS30A471DE350?
You can download the ALS30A471DE350 datasheet or visit the KEMET website for support.
Who is the manufacturer of ALS30A471DE350?
KEMET
