KEMET ALS40A223DB025 Aluminum Electrolytic Capacitor
The KEMET ALS40A223DB025 is a high-capacitance aluminum electrolytic capacitor designed for demanding industrial applications. With a capacitance of 22000uF and a voltage rating of 25VDC, this capacitor provides reliable power storage and filtering. Its screw terminal design ensures a secure and stable connection, while the wide operating temperature range of -40°C to +105°C makes it suitable for harsh environments. The capacitor's robust construction and long lifespan contribute to its overall reliability and performance in various applications, including power supplies, motor drives, and renewable energy systems.
KEMET ALS40A223DB025 Aluminum Electrolytic Capacitor Specifications:
- Series: ALS40
- Dielectric: Aluminum Electrolytic
- Description: Screw Terminal, Aluminum Electrolytic
- AEC-Q200: No
- Halogen Free: No
- Component Weight: 90 g
- Notes: Dimensions D And L Include Sleeving. MS (MxH) = M8x12. Mounting Clamp (Sold Separately): V3/H2/2736
- Shelf Life: 156 Weeks
- D: 36mm +/-1mm
- L: 62mm +/-2mm
- T: 7.1mm +/-0.5mm
- S: 12.8mm +/-0.5mm
- DT: 8mm +/-0.5mm
- LT: 67.5mm +/-1mm
- TD: 10mm MIN
- V: 8mm NOM
- Capacitance: 22,000 uF
- Capacitance Tolerance: 20%
- Voltage DC: 25 VDC
- Temperature Range: -40/+105°C
- Rated Temperature: 105°C
- Life: 6000 Hrs (Rated Voltage And Ripple Current At 105C), 10000 Hrs(Rated Voltage At 105C)
- Resistance: 17 mOhms (100Hz 20C), 15 mOhms(10kHz 20C)
- Ripple Current: 8.4 Amps (100Hz 105C), 8.8 Amps(10kHz 105C)
- Leakage Current: 1650 uA (5min 20°C)
- Sleeving: Yes
- Packaging: Bulk, Box
