KEMET ALS70A623DE025 Aluminum Electrolytic Capacitor
The KEMET ALS70A623DE025 is a robust aluminum electrolytic capacitor designed for a variety of industrial applications. With a high capacitance of 62,000 uF and a voltage rating of 25 VDC, this capacitor is suitable for power supply filtering, energy storage, and other demanding applications. Its screw terminal design simplifies integration into existing systems, while its wide operating temperature range ensures reliable performance in harsh environments. The capacitor's life expectancy is rated at 11,000 hours at 85°C with rated voltage and ripple current, or 22,000 hours at rated voltage.
KEMET ALS70A623DE025 Aluminum Electrolytic Capacitor Specifications:
- Supplier: KEMET
- Series: ALS70
- Dielectric: Aluminum Electrolytic
- Description: Screw Terminal, Aluminum Electrolytic
- Capacitance: 62,000 uF
- Capacitance Tolerance: 20%
- Voltage DC: 25 VDC, 28.75 VDC (Surge)
- Temperature Range: -40/+85C
- Rated Temperature: 85C
- Life: 11000 Hrs (Rated Voltage And Ripple Current At 85C), 22000 Hrs(Rated Voltage At 85C)
- Resistance: 25 mOhms (100Hz 20C), 23 mOhms(10kHz 20C)
- Ripple Current: 13.5 Amps (100Hz 85C), 15.1 Amps(10 kHz 85C)
- Leakage Current: 6000 uA
- Weight: 115 g
- Sleeving: Yes
- Packaging: Tray
- D: 36mm +/-1mm
- L: 82mm +/-2mm
- T: 7.14mm +/-0.5mm
- S: 12.8mm +/-0.5mm
- DT: 8mm +/-0.5mm
- LT: 87.5mm +/-1mm
- TD: 10mm MIN
- V: 8mm NOM
Buy the ALS70A623DE025 KEMET Aluminum Electrolytic Capacitor | myMectronic
Purchase the KEMET ALS70A623DE025 securely and conveniently online.
Buy Now
Frequently Asked Questions
Where can I buy KEMET ALS70A623DE025?
You can click on the BUY or RFQ button to purchase ALS70A623DE025 from an authorized KEMET distributor.
How do I troubleshoot issues or seek technical support for part ALS70A623DE025?
You can download the ALS70A623DE025 datasheet or visit the KEMET website for support.
Who is the manufacturer of ALS70A623DE025?
KEMET
